xFusion Drives & SSD
xFusion Hard Drives & SSD for FusionServer
Genuine xFusion SATA, NL-SAS, SAS and NVMe drives for FusionServer V5–V8 — from small boot SSD to 60 TB PCIe 5.0 NVMe. Every P/N is matched to the chassis generation.
Storage is the most frequently replaced and upgraded server component. The xFusion catalog spans read-intensive SATA SSD and high-RPM performance drives, NL-SAS and SAS nearline drives for bulk capacity, and PCIe NVMe SSD for latency-sensitive workloads. We verify the interface, form factor and carrier for your chassis before quoting.
1073Official part numbers
V5–V8Generation coverage
GenuinexFusion spare P/N
On requestQuote & lead time
Drive specifications at a glance
| Interfaces | SATA 6G, NL-SAS / SAS 12G (24G SAS-4), NVMe PCIe 4.0/5.0 |
|---|---|
| Form factors | 2.5″ SFF, 3.5″ LFF, M.2 80 mm, E3.S |
| Capacities | Boot SSD from 120/150 GB up to 60 TB NVMe |
| Workload types | Read-intensive, mixed-use, write-intensive |
| Hot-swap | Hot-pluggable in supported xFusion drive cages |
| Generations | FusionServer V5, V6, V7 and V8 — P/N varies |
| How to order | Send model + interface/capacity, or the drive P/N |
Featured product pages
Dedicated guides with full specifications, official part numbers and server compatibility:
- 1.6TB PCIe 5.0 NVMe SSD
- 1.92TB PCIe 5.0 NVMe SSD
- 3.2–3.84TB PCIe 5.0 NVMe SSD
- 7.68TB PCIe 5.0 NVMe SSD
- 480 GB SATA Enterprise SSD for xFusion Servers
- 960 GB SATA Enterprise SSD for xFusion Servers
- 1.92 TB SATA Enterprise SSD for xFusion Servers
- 3.84 TB SATA Enterprise SSD for xFusion Servers
- 600 GB SAS 12G 10K 2.5″ Enterprise Hard Drive for xFusion Servers
- 1.2 TB SAS 12G 10K 2.5″ Enterprise Hard Drive for xFusion Servers
- 1.8 TB SAS 12G 10K 2.5″ Enterprise Hard Drive for xFusion Servers
- 2.4 TB SAS 12G 10K 2.5″ Enterprise Hard Drive for xFusion Servers
- 4 TB SAS/SATA 3.5″ Nearline 7.2K Hard Drive for xFusion Servers
- 6 TB SAS/SATA 3.5″ Nearline 7.2K Hard Drive for xFusion Servers
- 8 TB SAS/SATA 3.5″ Nearline 7.2K Hard Drive for xFusion Servers
- 16 TB SATA 3.5″ Nearline 7.2K Hard Drive for xFusion Servers
Current xFusion drive specifications (V6–V8)
All capacities and part numbers are taken from the official xFusion spare-parts manuals. One specification (interface + capacity) is supplied under several OEM order codes for different chassis; expand any row to see every genuine part number. Capacities use decimal labeling (1 TB = 1,000 GB).
NVMe SSD480GBV6–V8e.g. 0255YCUY
NVMe SSD800GBV7–V7e.g. 0255Y688
NVMe SSD960GBV6–V8e.g. 0255Y118, 0255Y299
NVMe SSD1TBV5–V6e.g. 02312DBH, 02312DBJ
NVMe SSD1.6TBV5–V8e.g. 02312LKG, 02312LKT
NVMe SSD1.92TBV5–V8e.g. 02312TBL, 02312WFB
NVMe SSD2TBV5–V6e.g. 02312BVE, 02312BVF
NVMe SSD3.2TBV5–V8e.g. 02312LKE, 02312LKS
NVMe SSD3.84TBV5–V8e.g. 02312TBN, 02312WFJ
NVMe SSD4TBV5–V6e.g. 02312DBT, 02312DBU
NVMe SSD6.4TBV5–V8e.g. 02312PBP, 02312UMU
NVMe SSD7.68TBV5–V8e.g. 02312TBQ, 02312WFM
NVMe SSD8TBV5–V6e.g. 02312HER, 02312HES
NVMe SSD12.8TBV7–V8e.g. 0255YBTU, 0255YCSD
NVMe SSD15.36TBV5–V8e.g. 0255Y073, 0255Y074
NVMe SSD61.44TBV8–V8e.g. 0255YEFL
SAS SSD600GBV5–V8e.g. 02312RBW, 02540033
SAS SSD800GBV5–V6e.g. 02313FSF, 02313FSG
SAS SSD960GBV5–V7e.g. 02313ELL, 02313ELP
SAS SSD1.2TBV5–V8e.g. 02312RBV, 02540015
SAS SSD1.6TBV5–V7e.g. 02313FSJ, 02313FSK
SAS SSD1.8TBV5–V7e.g. 02312RBS, 02540035
SAS SSD1.92TBV5–V7e.g. 02313ELY, 02313EMA
SAS SSD2.4TBV5–V8e.g. 02312RCM, 02540036
SAS SSD3.2TBV5–V7e.g. 02313FSL, 02313FSR
SAS SSD3.84TBV5–V7e.g. 02313EMB, 02313EMC
SAS SSD4TBV5–V6e.g. 0254Y010
SAS SSD6TBV5–V6e.g. 0254Y011
SAS SSD6.4TBV5–V7e.g. 02313FSS, 02313FSV
SAS SSD7.68TBV5–V7e.g. 02313EMD, 02313EME
SAS SSD8TBV5–V6e.g. 0254Y012, 0254Y182
SAS SSD10TBV6–V6e.g. 0254Y084
SAS SSD12TBV7–V7e.g. 0254Y948
SAS SSD15.36TBV6–V6e.g. 0255YAKU
SAS SSD16TBV6–V7e.g. 0254Y082, 0254Y949
SAS SSD20TBV7–V8e.g. 0254Y243, 0254Y427
SAS SSD24TBV8–V8e.g. 0254Y764
SATA SSD6GBV5–V8e.g. 02312KGR, 02313ARC
SATA SSD240GBV5–V7e.g. 02312GND, 02312GNE
SATA SSD480GBV5–V8e.g. 02312GNF, 02312GNG
SATA SSD960GBV5–V8e.g. 02312GNH, 02312GNJ
SATA SSD1.92TBV5–V8e.g. 02312GNK, 02312GNL
SATA SSD2TBV5–V6e.g. 02311AYT
SATA SSD3.84TBV5–V8e.g. 02312GNM, 02312GNN
SATA SSD4TBV5–V8e.g. 02311AYV, 02540041
SATA SSD6TBV5–V7e.g. 02311DYQ, 02540042
SATA SSD7.68TBV7–V8e.g. 0255YARM, 0255YCPT
SATA SSD8TBV5–V8e.g. 02311JRE, 02540043
SATA SSD10TBV5–V7e.g. 02311SXE, 02540044
SATA SSD12TBV5–V7e.g. 02312DEK, 0254Y069
SATA SSD14TBV5–V7e.g. 02312HPC, 02312HPE
SATA SSD16TBV5–V8e.g. 02312PAN, 02540047
SATA SSD18TBV5–V7e.g. 02540048, 0254Y013
SATA SSD20TBV6–V8e.g. 0254Y075, 0254Y081
SATA SSD22TBV6–V7e.g. 0254Y080, 0254Y348
SATA SSD24TBV6–V8e.g. 0254Y364, 0254Y374
SATA SSD26TBV7–V7e.g. 0254Y684
SATA SSD30TBV7–V8e.g. 0254Y683, 0254Y795
SATA SSD32TBV7–V7e.g. 0254Y909
All official xFusion drive part numbers
Every current xFusion spare P/N, grouped by specification. Use the filter above to jump to a capacity or code, or open a group to list its part numbers. Each code links to the compatibility lookup for the exact server models it fits.
NVMe SSD 480GB — 1 official part numbers (V6–V8)
| # | Part number | Specification | Compatibility | Look up |
|---|---|---|---|---|
| 001 | 0255YCUY | 480GB, NVMe, M.2 | FusionServer V6–V8 | Look up → |
Not sure which of these fits your server? Check the xFusion compatibility center by model and ESN, or send us any part number for an exact match.
NVMe SSD 800GB — 1 official part numbers (V7–V7)
| # | Part number | Specification | Compatibility | Look up |
|---|---|---|---|---|
| 001 | 0255Y688 | 800GB, NVMe, 2.5″, write intensive | FusionServer V7 | Look up → |
Not sure which of these fits your server? Check the xFusion compatibility center by model and ESN, or send us any part number for an exact match.
NVMe SSD 960GB — 7 official part numbers (V6–V8)
| # | Part number | Specification | Compatibility | Look up |
|---|---|---|---|---|
| 001 | 0255Y118 | 960GB, NVMe, 2.5″, read intensive | FusionServer V6 | Look up → |
| 002 | 0255Y299 | 960GB, NVMe, 2.5″, read intensive | FusionServer V7–V8 | Look up → |
| 003 | 0255Y300 | 960GB, NVMe, 3.5″, read intensive | FusionServer V6–V8 | Look up → |
| 004 | 0255YAFJ | 960GB, NVMe, 2.5″, read intensive | FusionServer V7 | Look up → |
| 005 | 0255YCTN | 960GB, NVMe, M.2 | FusionServer V8 | Look up → |
| 006 | 0255YCUL | 960GB, NVMe, M.2 | FusionServer V6–V8 | Look up → |
| 007 | 0255YGFS | 960GB, NVMe, M.2 | FusionServer V7–V8 | Look up → |
Not sure which of these fits your server? Check the xFusion compatibility center by model and ESN, or send us any part number for an exact match.
NVMe SSD 1TB — 2 official part numbers (V5–V6)
| # | Part number | Specification | Compatibility | Look up |
|---|---|---|---|---|
| 001 | 02312DBH | 1TB, NVMe, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 002 | 02312DBJ | 1TB, NVMe, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
Not sure which of these fits your server? Check the xFusion compatibility center by model and ESN, or send us any part number for an exact match.
NVMe SSD 1.6TB — 47 official part numbers (V5–V8)
| # | Part number | Specification | Compatibility | Look up |
|---|---|---|---|---|
| 001 | 02312LKG | 1.6TB, NVMe, 2.5″ | FusionServer V5–V6 | Look up → |
| 002 | 02312LKT | 1.6TB, NVMe, 3.5″ | FusionServer V5–V6 | Look up → |
| 003 | 02312WFQ | 1.6TB, NVMe, 2.5″, mixed use | FusionServer V6 | Look up → |
| 004 | 02312WFR | 1.6TB, NVMe, 3.5″, mixed use | FusionServer V6 | Look up → |
| 005 | 0255Y137 | 1.6TB, NVMe, 2.5″, mixed use | FusionServer V5–V6 | Look up → |
| 006 | 0255Y138 | 1.6TB, NVMe, 3.5″, mixed use | FusionServer V6 | Look up → |
| 007 | 0255Y147 | 1.6TB, NVMe, 2.5″, mixed use | FusionServer V5–V6 | Look up → |
| 008 | 0255Y148 | 1.6TB, NVMe, 3.5″, mixed use | FusionServer V5–V6 | Look up → |
| 009 | 0255Y192 | 1.6TB, NVMe, 2.5″, mixed use | FusionServer V5–V6 | Look up → |
| 010 | 0255Y193 | 1.6TB, NVMe, 3.5″, mixed use | FusionServer V5–V6 | Look up → |
| 011 | 0255Y201 | 1.6TB, NVMe, 2.5″, mixed use | FusionServer V5–V6 | Look up → |
| 012 | 0255Y290 | 1.6TB, NVMe, 2.5″, mixed use | FusionServer V6 | Look up → |
| 013 | 0255Y321 | 1.6TB, NVMe, 2.5″, mixed use | FusionServer V6 | Look up → |
| 014 | 0255Y364 | 1.6TB, NVMe, 2.5″, mixed use | FusionServer V5–V6 | Look up → |
| 015 | 0255Y385 | 1.6TB, NVMe, 2.5″, mixed use | FusionServer V5–V6 | Look up → |
| 016 | 0255Y386 | 1.6TB, NVMe, 3.5″, mixed use | FusionServer V5–V6 | Look up → |
| 017 | 0255Y470 | 1.6TB, NVMe, 2.5″, mixed use | FusionServer V7 | Look up → |
| 018 | 0255Y471 | 1.6TB, NVMe, 3.5″, mixed use | FusionServer V7 | Look up → |
| 019 | 0255Y476 | 1.6TB, NVMe, 2.5″, mixed use | FusionServer V7 | Look up → |
| 020 | 0255Y477 | 1.6TB, NVMe, 3.5″, mixed use | FusionServer V7 | Look up → |
| 021 | 0255Y532 | 1.6TB, NVMe, 2.5″, mixed use | FusionServer V6 | Look up → |
| 022 | 0255Y622 | 1.6TB, NVMe, 2.5″, mixed use | FusionServer V7 | Look up → |
| 023 | 0255Y623 | 1.6TB, NVMe, 3.5″, mixed use | FusionServer V6–V7 | Look up → |
| 024 | 0255Y652 | 1.6TB, NVMe, 2.5″, mixed use | FusionServer V5–V6 | Look up → |
| 025 | 0255Y653 | 1.6TB, NVMe, 3.5″, mixed use | FusionServer V5–V6 | Look up → |
| 026 | 0255Y901 | 1.6TB, NVMe, 2.5″, mixed use | FusionServer V7 | Look up → |
| 027 | 0255Y902 | 1.6TB, NVMe, 3.5″, mixed use | FusionServer V6–V7 | Look up → |
| 028 | 0255YALS | 1.6TB, NVMe, 2.5″, mixed use | FusionServer V5–V6 | Look up → |
| 029 | 0255YATG | 1.6TB, NVMe PCIe 4.0, 2.5″, mixed use | FusionServer V6 | Look up → |
| 030 | 0255YAVH | 1.6TB, NVMe, 2.5″, mixed use | FusionServer V7 | Look up → |
| 031 | 0255YAVJ | 1.6TB, NVMe, 3.5″, mixed use | FusionServer V7 | Look up → |
| 032 | 0255YAYU | 1.6TB, NVMe, 2.5″, mixed use | FusionServer V7 | Look up → |
| 033 | 0255YAYV | 1.6TB, NVMe, 3.5″, mixed use | FusionServer V7 | Look up → |
| 034 | 0255YBER | 1.6TB, NVMe, 2.5″, mixed use | FusionServer V7 | Look up → |
| 035 | 0255YBES | 1.6TB, NVMe, 3.5″, mixed use | FusionServer V7 | Look up → |
| 036 | 0255YBET | 1.6TB, NVMe, 2.5″, mixed use | FusionServer V6 | Look up → |
| 037 | 0255YBGJ | 1.6TB, NVMe, 2.5″, mixed use | FusionServer V6 | Look up → |
| 038 | 0255YBGK | 1.6TB, NVMe, 3.5″, mixed use | FusionServer V6 | Look up → |
| 039 | 0255YBGL | 1.6TB, NVMe, 2.5″, mixed use | FusionServer V7–V8 | Look up → |
| 040 | 0255YBGM | 1.6TB, NVMe, 3.5″, mixed use | FusionServer V7–V8 | Look up → |
| 041 | 0255YBUL | 1.6TB, NVMe, 2.5″, mixed use | FusionServer V6 | Look up → |
| 042 | 0255YBUM | 1.6TB, NVMe, 3.5″, mixed use | FusionServer V6 | Look up → |
| 043 | 0255YBUS | 1.6TB, NVMe, 2.5″, mixed use | FusionServer V7 | Look up → |
| 044 | 0255YBUT | 1.6TB, NVMe, 3.5″, mixed use | FusionServer V7 | Look up → |
| 045 | 0255YDEA | 1.6TB, NVMe, 2.5″, mixed use | FusionServer V8 | Look up → |
| 046 | 0255YDQE | 1.6TB, NVMe PCIe 5.0, 2.5″, mixed use | FusionServer V8 | Look up → |
| 047 | 0257Y002 | 1.6TB, NVMe PCIe 4.0, mixed use | FusionServer V5–V6 | Look up → |
Not sure which of these fits your server? Check the xFusion compatibility center by model and ESN, or send us any part number for an exact match.
NVMe SSD 1.92TB — 48 official part numbers (V5–V8)
| # | Part number | Specification | Compatibility | Look up |
|---|---|---|---|---|
| 001 | 02312TBL | 1.92TB, NVMe, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 002 | 02312WFB | 1.92TB, NVMe, 2.5″, read intensive | FusionServer V6 | Look up → |
| 003 | 02312WFC | 1.92TB, NVMe, 3.5″, read intensive | FusionServer V6 | Look up → |
| 004 | 0255Y002 | 1.92TB, NVMe, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 005 | 0255Y003 | 1.92TB, NVMe, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 006 | 0255Y141 | 1.92TB, NVMe, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 007 | 0255Y142 | 1.92TB, NVMe, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 008 | 0255Y180 | 1.92TB, NVMe, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 009 | 0255Y181 | 1.92TB, NVMe, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 010 | 0255Y211 | 1.92TB, NVMe, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 011 | 0255Y301 | 1.92TB, NVMe, 2.5″, read intensive | FusionServer V7–V8 | Look up → |
| 012 | 0255Y302 | 1.92TB, NVMe, 3.5″, read intensive | FusionServer V6–V8 | Look up → |
| 013 | 0255Y337 | 1.92TB, NVMe, 2.5″, read intensive | FusionServer V7 | Look up → |
| 014 | 0255Y338 | 1.92TB, NVMe, 3.5″, read intensive | FusionServer V7 | Look up → |
| 015 | 0255Y391 | 1.92TB, NVMe, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 016 | 0255Y392 | 1.92TB, NVMe, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 017 | 0255Y464 | 1.92TB, NVMe, 2.5″, read intensive | FusionServer V7 | Look up → |
| 018 | 0255Y465 | 1.92TB, NVMe, 3.5″, read intensive | FusionServer V6–V7 | Look up → |
| 019 | 0255Y515 | 1.92TB, NVMe, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 020 | 0255Y516 | 1.92TB, NVMe, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 021 | 0255Y616 | 1.92TB, NVMe, 2.5″, read intensive | FusionServer V7–V8 | Look up → |
| 022 | 0255Y617 | 1.92TB, NVMe, 3.5″, read intensive | FusionServer V7–V8 | Look up → |
| 023 | 0255Y648 | 1.92TB, NVMe, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 024 | 0255Y649 | 1.92TB, NVMe, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 025 | 0255Y895 | 1.92TB, NVMe, 2.5″, read intensive | FusionServer V7 | Look up → |
| 026 | 0255Y896 | 1.92TB, NVMe, 3.5″, read intensive | FusionServer V6–V7 | Look up → |
| 027 | 0255Y928 | 1.92TB, NVMe, M.2 | FusionServer V8 | Look up → |
| 028 | 0255Y947 | 1.92TB, NVMe, 3.5″, read intensive | FusionServer V6 | Look up → |
| 029 | 0255Y971 | 1.92TB, NVMe, 2.5″, read intensive | FusionServer V7 | Look up → |
| 030 | 0255YAMX | 1.92TB, NVMe, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 031 | 0255YANC | 1.92TB, NVMe, 2.5″, read intensive | FusionServer V7 | Look up → |
| 032 | 0255YAXL | 1.92TB, NVMe, 2.5″, read intensive | FusionServer V8 | Look up → |
| 033 | 0255YAXS | 1.92TB, NVMe, 2.5″, read intensive | FusionServer V8 | Look up → |
| 034 | 0255YBAN | 1.92TB, NVMe, 2.5″, read intensive | FusionServer V7–V8 | Look up → |
| 035 | 0255YBAP | 1.92TB, NVMe, 3.5″, read intensive | FusionServer V7–V8 | Look up → |
| 036 | 0255YBVD | 1.92TB, NVMe, 2.5″, read intensive | FusionServer V7 | Look up → |
| 037 | 0255YBVE | 1.92TB, NVMe, 3.5″, read intensive | FusionServer V7 | Look up → |
| 038 | 0255YBVM | 1.92TB, NVMe, 2.5″, read intensive | FusionServer V6 | Look up → |
| 039 | 0255YBVN | 1.92TB, NVMe, 3.5″, read intensive | FusionServer V6 | Look up → |
| 040 | 0255YBWE | 1.92TB, NVMe, M.2 | FusionServer V6–V8 | Look up → |
| 041 | 0255YCHW | 1.92TB, NVMe, 3.5″, read intensive | FusionServer V7 | Look up → |
| 042 | 0255YCHX | 1.92TB, NVMe, 3.5″, read intensive | FusionServer V7 | Look up → |
| 043 | 0255YCJK | 1.92TB, NVMe, 3.5″, read intensive | FusionServer V6 | Look up → |
| 044 | 0255YCKC | 1.92TB, NVMe, 3.5″, read intensive | FusionServer V8 | Look up → |
| 045 | 0255YCPA | 1.92TB, NVMe, 2.5″, read intensive | FusionServer V6 | Look up → |
| 046 | 0255YCPG | 1.92TB, NVMe, 2.5″, read intensive | FusionServer V8 | Look up → |
| 047 | 0255YDJE | 1.92TB, NVMe PCIe 5.0, 2.5″, read intensive | FusionServer V8 | Look up → |
| 048 | 0255YDJF | 1.92TB, NVMe PCIe 5.0, 3.5″, read intensive | FusionServer V8 | Look up → |
Not sure which of these fits your server? Check the xFusion compatibility center by model and ESN, or send us any part number for an exact match.
NVMe SSD 2TB — 2 official part numbers (V5–V6)
| # | Part number | Specification | Compatibility | Look up |
|---|---|---|---|---|
| 001 | 02312BVE | 2TB, NVMe, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 002 | 02312BVF | 2TB, NVMe, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
Not sure which of these fits your server? Check the xFusion compatibility center by model and ESN, or send us any part number for an exact match.
NVMe SSD 3.2TB — 69 official part numbers (V5–V8)
| # | Part number | Specification | Compatibility | Look up |
|---|---|---|---|---|
| 001 | 02312LKE | 3.2TB, NVMe, 2.5″ | FusionServer V5–V6 | Look up → |
| 002 | 02312LKS | 3.2TB, NVMe, 3.5″ | FusionServer V5–V6 | Look up → |
| 003 | 02312WFS | 3.2TB, NVMe, 2.5″, mixed use | FusionServer V6 | Look up → |
| 004 | 02312WFT | 3.2TB, NVMe, 3.5″, mixed use | FusionServer V6 | Look up → |
| 005 | 0255Y135 | 3.2TB, NVMe, 2.5″, mixed use | FusionServer V5–V6 | Look up → |
| 006 | 0255Y136 | 3.2TB, NVMe, 3.5″, mixed use | FusionServer V6 | Look up → |
| 007 | 0255Y149 | 3.2TB, NVMe, 2.5″, mixed use | FusionServer V5–V6 | Look up → |
| 008 | 0255Y150 | 3.2TB, NVMe, 3.5″, mixed use | FusionServer V5–V6 | Look up → |
| 009 | 0255Y194 | 3.2TB, NVMe, 2.5″, mixed use | FusionServer V5–V6 | Look up → |
| 010 | 0255Y195 | 3.2TB, NVMe, 3.5″, mixed use | FusionServer V5–V6 | Look up → |
| 011 | 0255Y203 | 3.2TB, NVMe, 2.5″, mixed use | FusionServer V5–V6 | Look up → |
| 012 | 0255Y286 | 3.2TB, NVMe, 2.5″, mixed use | FusionServer V6 | Look up → |
| 013 | 0255Y288 | 3.2TB, NVMe, 2.5″, mixed use | FusionServer V6 | Look up → |
| 014 | 0255Y322 | 3.2TB, NVMe, 2.5″, mixed use | FusionServer V6 | Look up → |
| 015 | 0255Y366 | 3.2TB, NVMe, 2.5″, mixed use | FusionServer V5–V6 | Look up → |
| 016 | 0255Y387 | 3.2TB, NVMe, 2.5″, mixed use | FusionServer V5–V6 | Look up → |
| 017 | 0255Y388 | 3.2TB, NVMe, 3.5″, mixed use | FusionServer V5–V6 | Look up → |
| 018 | 0255Y472 | 3.2TB, NVMe, 2.5″, mixed use | FusionServer V7 | Look up → |
| 019 | 0255Y473 | 3.2TB, NVMe, 3.5″, mixed use | FusionServer V7 | Look up → |
| 020 | 0255Y478 | 3.2TB, NVMe, 2.5″, mixed use | FusionServer V7 | Look up → |
| 021 | 0255Y479 | 3.2TB, NVMe, 3.5″, mixed use | FusionServer V7 | Look up → |
| 022 | 0255Y533 | 3.2TB, NVMe, 2.5″, mixed use | FusionServer V6 | Look up → |
| 023 | 0255Y624 | 3.2TB, NVMe, 2.5″, mixed use | FusionServer V7 | Look up → |
| 024 | 0255Y625 | 3.2TB, NVMe, 3.5″, mixed use | FusionServer V6–V7 | Look up → |
| 025 | 0255Y654 | 3.2TB, NVMe, 2.5″, mixed use | FusionServer V5–V6 | Look up → |
| 026 | 0255Y655 | 3.2TB, NVMe, 3.5″, mixed use | FusionServer V5–V6 | Look up → |
| 027 | 0255Y713 | 3.2TB, NVMe, 2.5″, mixed use | FusionServer V6 | Look up → |
| 028 | 0255Y717 | 3.2TB, NVMe, 2.5″, mixed use | FusionServer V6 | Look up → |
| 029 | 0255Y856 | 3.2TB, NVMe, 2.5″, mixed use | FusionServer V7–V8 | Look up → |
| 030 | 0255Y857 | 3.2TB, NVMe, 3.5″, mixed use | FusionServer V7 | Look up → |
| 031 | 0255Y903 | 3.2TB, NVMe, 2.5″, mixed use | FusionServer V7 | Look up → |
| 032 | 0255Y904 | 3.2TB, NVMe, 3.5″, mixed use | FusionServer V6–V7 | Look up → |
| 033 | 0255YASK | 3.2TB, NVMe, 2.5″, mixed use | FusionServer V7 | Look up → |
| 034 | 0255YASL | 3.2TB, NVMe, 3.5″, mixed use | FusionServer V7 | Look up → |
| 035 | 0255YATB | 3.2TB, NVMe, 2.5″, mixed use | FusionServer V6 | Look up → |
| 036 | 0255YATH | 3.2TB, NVMe PCIe 4.0, 2.5″, mixed use | FusionServer V6 | Look up → |
| 037 | 0255YAVD | 3.2TB, NVMe, 2.5″, mixed use | FusionServer V7 | Look up → |
| 038 | 0255YAVE | 3.2TB, NVMe, 3.5″, mixed use | FusionServer V7 | Look up → |
| 039 | 0255YAYW | 3.2TB, NVMe, 2.5″, mixed use | FusionServer V7 | Look up → |
| 040 | 0255YAYX | 3.2TB, NVMe, 3.5″, mixed use | FusionServer V6–V7 | Look up → |
| 041 | 0255YBAD | 3.2TB, NVMe, 2.5″, mixed use | FusionServer V6 | Look up → |
| 042 | 0255YBBL | 3.2TB, NVMe, 3.5″, mixed use | FusionServer V7 | Look up → |
| 043 | 0255YBCS | 3.2TB, NVMe, 2.5″, mixed use | FusionServer V7 | Look up → |
| 044 | 0255YBCT | 3.2TB, NVMe, 3.5″, mixed use | FusionServer V7 | Look up → |
| 045 | 0255YBEX | 3.2TB, NVMe, 2.5″, mixed use | FusionServer V6 | Look up → |
| 046 | 0255YBFC | 3.2TB, NVMe, 2.5″, mixed use | FusionServer V7 | Look up → |
| 047 | 0255YBFD | 3.2TB, NVMe, 3.5″, mixed use | FusionServer V7 | Look up → |
| 048 | 0255YBHS | 3.2TB, NVMe, 2.5″, mixed use | FusionServer V7 | Look up → |
| 049 | 0255YBTQ | 3.2TB, NVMe, 2.5″, mixed use | FusionServer V6 | Look up → |
| 050 | 0255YBTR | 3.2TB, NVMe, 3.5″, mixed use | FusionServer V6 | Look up → |
| 051 | 0255YBTS | 3.2TB, NVMe, 3.5″, mixed use | FusionServer V7 | Look up → |
| 052 | 0255YBUJ | 3.2TB, NVMe, 2.5″, mixed use | FusionServer V6 | Look up → |
| 053 | 0255YBUK | 3.2TB, NVMe, 3.5″, mixed use | FusionServer V6 | Look up → |
| 054 | 0255YBUQ | 3.2TB, NVMe, 2.5″, mixed use | FusionServer V7 | Look up → |
| 055 | 0255YBUR | 3.2TB, NVMe, 3.5″, mixed use | FusionServer V7 | Look up → |
| 056 | 0255YCFU | 3.2TB, NVMe, 2.5″, mixed use | FusionServer V7 | Look up → |
| 057 | 0255YCFY | 3.2TB, NVMe, 3.5″, mixed use | FusionServer V7 | Look up → |
| 058 | 0255YCGX | 3.2TB, NVMe, 2.5″, mixed use | FusionServer V7 | Look up → |
| 059 | 0255YCGY | 3.2TB, NVMe, 3.5″, mixed use | FusionServer V7 | Look up → |
| 060 | 0255YDDB | 3.2TB, NVMe, 3.5″, mixed use | FusionServer V7 | Look up → |
| 061 | 0255YDDC | 3.2TB, NVMe, 3.5″, mixed use | FusionServer V7 | Look up → |
| 062 | 0255YDEB | 3.2TB, NVMe PCIe 5.0, 2.5″, mixed use | FusionServer V8 | Look up → |
| 063 | 0255YDJG | 3.2TB, NVMe PCIe 5.0, 2.5″, mixed use | FusionServer V8 | Look up → |
| 064 | 0255YDJH | 3.2TB, NVMe PCIe 5.0, 3.5″, mixed use | FusionServer V8 | Look up → |
| 065 | 0255YEGH | 3.2TB, NVMe PCIe 5.0, 2.5″, mixed use | FusionServer V8 | Look up → |
| 066 | 0255YEGJ | 3.2TB, NVMe PCIe 5.0, 3.5″, mixed use | FusionServer V8 | Look up → |
| 067 | 0255YEMD | 3.2TB, NVMe PCIe 4.0, 2.5″, mixed use | FusionServer V8 | Look up → |
| 068 | 0255YFGL | 3.2TB, NVMe PCIe 5.0, 2.5″ | FusionServer V8 | Look up → |
| 069 | 0257Y003 | 3.2TB, NVMe PCIe 4.0, mixed use | FusionServer V5–V6 | Look up → |
Not sure which of these fits your server? Check the xFusion compatibility center by model and ESN, or send us any part number for an exact match.
NVMe SSD 3.84TB — 83 official part numbers (V5–V8)
| # | Part number | Specification | Compatibility | Look up |
|---|---|---|---|---|
| 001 | 02312TBN | 3.84TB, NVMe, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 002 | 02312WFJ | 3.84TB, NVMe, 2.5″, read intensive | FusionServer V6 | Look up → |
| 003 | 02312WFK | 3.84TB, NVMe, 3.5″, read intensive | FusionServer V6 | Look up → |
| 004 | 0255Y004 | 3.84TB, NVMe, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 005 | 0255Y005 | 3.84TB, NVMe, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 006 | 0255Y039 | 3.84TB, NVMe, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 007 | 0255Y040 | 3.84TB, NVMe, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 008 | 0255Y102 | 3.84TB, NVMe, 2.5″, read intensive | FusionServer V6 | Look up → |
| 009 | 0255Y143 | 3.84TB, NVMe, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 010 | 0255Y144 | 3.84TB, NVMe, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 011 | 0255Y182 | 3.84TB, NVMe, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 012 | 0255Y183 | 3.84TB, NVMe, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 013 | 0255Y213 | 3.84TB, NVMe, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 014 | 0255Y303 | 3.84TB, NVMe, 2.5″, read intensive | FusionServer V7–V8 | Look up → |
| 015 | 0255Y304 | 3.84TB, NVMe, 3.5″, read intensive | FusionServer V6–V8 | Look up → |
| 016 | 0255Y339 | 3.84TB, NVMe, 2.5″, read intensive | FusionServer V7 | Look up → |
| 017 | 0255Y340 | 3.84TB, NVMe, 3.5″, read intensive | FusionServer V7 | Look up → |
| 018 | 0255Y393 | 3.84TB, NVMe, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 019 | 0255Y394 | 3.84TB, NVMe, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 020 | 0255Y466 | 3.84TB, NVMe, 2.5″, read intensive | FusionServer V7 | Look up → |
| 021 | 0255Y467 | 3.84TB, NVMe, 3.5″, read intensive | FusionServer V6–V7 | Look up → |
| 022 | 0255Y490 | 3.84TB, NVMe, 2.5″, read intensive | FusionServer V6 | Look up → |
| 023 | 0255Y517 | 3.84TB, NVMe, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 024 | 0255Y518 | 3.84TB, NVMe, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 025 | 0255Y618 | 3.84TB, NVMe, 2.5″, read intensive | FusionServer V7 | Look up → |
| 026 | 0255Y619 | 3.84TB, NVMe, 3.5″, read intensive | FusionServer V7 | Look up → |
| 027 | 0255Y650 | 3.84TB, NVMe, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 028 | 0255Y651 | 3.84TB, NVMe, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 029 | 0255Y678 | 3.84TB, NVMe, 3.5″, read intensive | FusionServer V6 | Look up → |
| 030 | 0255Y897 | 3.84TB, NVMe, 2.5″, read intensive | FusionServer V7 | Look up → |
| 031 | 0255Y898 | 3.84TB, NVMe, 3.5″, read intensive | FusionServer V6–V7 | Look up → |
| 032 | 0255Y916 | 3.84TB, NVMe, 2.5″, read intensive | FusionServer V7 | Look up → |
| 033 | 0255Y948 | 3.84TB, NVMe, 3.5″, read intensive | FusionServer V6 | Look up → |
| 034 | 0255Y951 | 3.84TB, NVMe, 3.5″, read intensive | FusionServer V7 | Look up → |
| 035 | 0255Y972 | 3.84TB, NVMe, 2.5″, read intensive | FusionServer V7 | Look up → |
| 036 | 0255YABN | 3.84TB, NVMe, 2.5″, read intensive | FusionServer V6 | Look up → |
| 037 | 0255YABP | 3.84TB, NVMe, 3.5″, read intensive | FusionServer V6 | Look up → |
| 038 | 0255YABQ | 3.84TB, NVMe, 2.5″, read intensive | FusionServer V6 | Look up → |
| 039 | 0255YABR | 3.84TB, NVMe, 3.5″, read intensive | FusionServer V6 | Look up → |
| 040 | 0255YABU | 3.84TB, NVMe, 2.5″, read intensive | FusionServer V6 | Look up → |
| 041 | 0255YABV | 3.84TB, NVMe, 3.5″, read intensive | FusionServer V6 | Look up → |
| 042 | 0255YADX | 3.84TB, NVMe, 3.5″, read intensive | FusionServer V7 | Look up → |
| 043 | 0255YAEF | 3.84TB, NVMe, 2.5″, read intensive | FusionServer V7 | Look up → |
| 044 | 0255YAJX | 3.84TB, NVMe, 2.5″, read intensive | FusionServer V7 | Look up → |
| 045 | 0255YAJY | 3.84TB, NVMe, 2.5″, read intensive | FusionServer V7 | Look up → |
| 046 | 0255YAKA | 3.84TB, NVMe PCIe 4.0, 3.5″, read intensive | FusionServer V7 | Look up → |
| 047 | 0255YAKJ | 3.84TB, NVMe, 2.5″, read intensive | FusionServer V7 | Look up → |
| 048 | 0255YAKK | 3.84TB, NVMe PCIe 4.0, 3.5″, read intensive | FusionServer V7 | Look up → |
| 049 | 0255YAKV | 3.84TB, NVMe, 2.5″, read intensive | FusionServer V6 | Look up → |
| 050 | 0255YANG | 3.84TB, NVMe, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 051 | 0255YANU | 3.84TB, NVMe, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 052 | 0255YANW | 3.84TB, NVMe, 2.5″, read intensive | FusionServer V7 | Look up → |
| 053 | 0255YARW | 3.84TB, NVMe, 3.5″, read intensive | FusionServer V6 | Look up → |
| 054 | 0255YARX | 3.84TB, NVMe, 2.5″, read intensive | FusionServer V7–V8 | Look up → |
| 055 | 0255YASW | 3.84TB, NVMe, 2.5″, read intensive | FusionServer V7 | Look up → |
| 056 | 0255YASY | 3.84TB, NVMe, 3.5″, read intensive | FusionServer V7 | Look up → |
| 057 | 0255YATY | 3.84TB, NVMe, 2.5″, read intensive | FusionServer V6 | Look up → |
| 058 | 0255YAXU | 3.84TB, NVMe, 3.5″, read intensive | FusionServer V6 | Look up → |
| 059 | 0255YBAQ | 3.84TB, NVMe, 2.5″, read intensive | FusionServer V7–V8 | Look up → |
| 060 | 0255YBAR | 3.84TB, NVMe, 3.5″, read intensive | FusionServer V7–V8 | Look up → |
| 061 | 0255YBVF | 3.84TB, NVMe, 2.5″, read intensive | FusionServer V7 | Look up → |
| 062 | 0255YBVG | 3.84TB, NVMe, 3.5″, read intensive | FusionServer V7 | Look up → |
| 063 | 0255YBVP | 3.84TB, NVMe, 2.5″, read intensive | FusionServer V6 | Look up → |
| 064 | 0255YBVQ | 3.84TB, NVMe, 3.5″, read intensive | FusionServer V6 | Look up → |
| 065 | 0255YCHC | 3.84TB, NVMe, 2.5″, read intensive | FusionServer V7 | Look up → |
| 066 | 0255YCHD | 3.84TB, NVMe, 3.5″, read intensive | FusionServer V7 | Look up → |
| 067 | 0255YCHE | 3.84TB, NVMe, 2.5″, read intensive | FusionServer V7 | Look up → |
| 068 | 0255YCHF | 3.84TB, NVMe, 3.5″, read intensive | FusionServer V7 | Look up → |
| 069 | 0255YCHG | 3.84TB, NVMe, 2.5″, read intensive | FusionServer V7 | Look up → |
| 070 | 0255YCHH | 3.84TB, NVMe, 3.5″, read intensive | FusionServer V7 | Look up → |
| 071 | 0255YCKL | 3.84TB, NVMe, 2.5″, read intensive | FusionServer V7 | Look up → |
| 072 | 0255YDBF | 3.84TB, NVMe PCIe 5.0, 3.5″, read intensive | FusionServer V8 | Look up → |
| 073 | 0255YDEC | 3.84TB, NVMe PCIe 5.0, 3.5″, read intensive | FusionServer V7–V8 | Look up → |
| 074 | 0255YDED | 3.84TB, NVMe PCIe 5.0, 2.5″, read intensive | FusionServer V7–V8 | Look up → |
| 075 | 0255YDFQ | 3.84TB, NVMe, 2.5″, read intensive | FusionServer V7 | Look up → |
| 076 | 0255YDFR | 3.84TB, NVMe PCIe 4.0, 3.5″, read intensive | FusionServer V7 | Look up → |
| 077 | 0255YDJC | 3.84TB, NVMe PCIe 5.0, 2.5″, read intensive | FusionServer V8 | Look up → |
| 078 | 0255YDJD | 3.84TB, NVMe PCIe 5.0, 3.5″, read intensive | FusionServer V8 | Look up → |
| 079 | 0255YDVJ | 3.84TB, NVMe PCIe 5.0, 2.5″, read intensive | FusionServer V7 | Look up → |
| 080 | 0255YEGF | 3.84TB, NVMe PCIe 5.0, 2.5″, read intensive | FusionServer V8 | Look up → |
| 081 | 0255YEGG | 3.84TB, NVMe PCIe 5.0, 3.5″, read intensive | FusionServer V8 | Look up → |
| 082 | 0255YENP | 3.84TB, NVMe, 2.5″, read intensive | FusionServer V7 | Look up → |
| 083 | 0255YFHK | 3.84TB, NVMe PCIe 5.0, E3.S, read intensive | FusionServer V8 | Look up → |
Not sure which of these fits your server? Check the xFusion compatibility center by model and ESN, or send us any part number for an exact match.
NVMe SSD 4TB — 2 official part numbers (V5–V6)
| # | Part number | Specification | Compatibility | Look up |
|---|---|---|---|---|
| 001 | 02312DBT | 4TB, NVMe, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 002 | 02312DBU | 4TB, NVMe, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
Not sure which of these fits your server? Check the xFusion compatibility center by model and ESN, or send us any part number for an exact match.
NVMe SSD 6.4TB — 51 official part numbers (V5–V8)
| # | Part number | Specification | Compatibility | Look up |
|---|---|---|---|---|
| 001 | 02312PBP | 6.4TB, NVMe, 2.5″ | FusionServer V5–V6 | Look up → |
| 002 | 02312UMU | 6.4TB, NVMe, 3.5″ | FusionServer V5–V6 | Look up → |
| 003 | 0255Y134 | 6.4TB, NVMe, 2.5″, mixed use | FusionServer V5–V6 | Look up → |
| 004 | 0255Y151 | 6.4TB, NVMe, 2.5″, mixed use | FusionServer V5–V6 | Look up → |
| 005 | 0255Y196 | 6.4TB, NVMe, 3.5″, mixed use | FusionServer V5–V6 | Look up → |
| 006 | 0255Y205 | 6.4TB, NVMe, 2.5″, mixed use | FusionServer V5–V6 | Look up → |
| 007 | 0255Y215 | 6.4TB, NVMe, 2.5″, mixed use | FusionServer V5–V6 | Look up → |
| 008 | 0255Y368 | 6.4TB, NVMe, 2.5″, mixed use | FusionServer V5–V6 | Look up → |
| 009 | 0255Y389 | 6.4TB, NVMe, 2.5″, mixed use | FusionServer V5–V6 | Look up → |
| 010 | 0255Y390 | 6.4TB, NVMe, 3.5″, mixed use | FusionServer V5–V6 | Look up → |
| 011 | 0255Y474 | 6.4TB, NVMe, 2.5″, mixed use | FusionServer V7 | Look up → |
| 012 | 0255Y475 | 6.4TB, NVMe, 3.5″, mixed use | FusionServer V7 | Look up → |
| 013 | 0255Y480 | 6.4TB, NVMe, 2.5″, mixed use | FusionServer V7 | Look up → |
| 014 | 0255Y481 | 6.4TB, NVMe, 3.5″, mixed use | FusionServer V7 | Look up → |
| 015 | 0255Y626 | 6.4TB, NVMe, 2.5″, mixed use | FusionServer V7 | Look up → |
| 016 | 0255Y627 | 6.4TB, NVMe, 3.5″, mixed use | FusionServer V6–V7 | Look up → |
| 017 | 0255Y656 | 6.4TB, NVMe, 2.5″, mixed use | FusionServer V5–V6 | Look up → |
| 018 | 0255Y657 | 6.4TB, NVMe, 3.5″, mixed use | FusionServer V5–V6 | Look up → |
| 019 | 0255Y905 | 6.4TB, NVMe, 2.5″, mixed use | FusionServer V7 | Look up → |
| 020 | 0255Y906 | 6.4TB, NVMe, 3.5″, mixed use | FusionServer V6–V7 | Look up → |
| 021 | 0255YABJ | 6.4TB, NVMe, 2.5″, mixed use | FusionServer V7 | Look up → |
| 022 | 0255YAMR | 6.4TB, NVMe, 2.5″, mixed use | FusionServer V5–V6 | Look up → |
| 023 | 0255YASA | 6.4TB, NVMe, 3.5″, mixed use | FusionServer V7 | Look up → |
| 024 | 0255YASM | 6.4TB, NVMe, 2.5″, mixed use | FusionServer V7 | Look up → |
| 025 | 0255YATQ | 6.4TB, NVMe, 2.5″, mixed use | FusionServer V6 | Look up → |
| 026 | 0255YAVF | 6.4TB, NVMe, 2.5″, mixed use | FusionServer V7 | Look up → |
| 027 | 0255YAVG | 6.4TB, NVMe, 3.5″, mixed use | FusionServer V7 | Look up → |
| 028 | 0255YAYY | 6.4TB, NVMe, 2.5″, mixed use | FusionServer V7–V8 | Look up → |
| 029 | 0255YBAA | 6.4TB, NVMe, 3.5″, mixed use | FusionServer V6–V7 | Look up → |
| 030 | 0255YBAF | 6.4TB, NVMe, 2.5″, mixed use | FusionServer V6 | Look up → |
| 031 | 0255YBAY | 6.4TB, NVMe, 2.5″, mixed use | FusionServer V6 | Look up → |
| 032 | 0255YBBD | 6.4TB, NVMe, 2.5″, mixed use | FusionServer V7–V8 | Look up → |
| 033 | 0255YBBE | 6.4TB, NVMe, 3.5″, mixed use | FusionServer V7 | Look up → |
| 034 | 0255YBNW | 6.4TB, NVMe, 2.5″, mixed use | FusionServer V7 | Look up → |
| 035 | 0255YBNX | 6.4TB, NVMe, 3.5″, mixed use | FusionServer V7 | Look up → |
| 036 | 0255YBTE | 6.4TB, NVMe, 2.5″, mixed use | FusionServer V6 | Look up → |
| 037 | 0255YBUG | 6.4TB, NVMe, 2.5″, mixed use | FusionServer V6 | Look up → |
| 038 | 0255YBUH | 6.4TB, NVMe, 3.5″, mixed use | FusionServer V6 | Look up → |
| 039 | 0255YBUN | 6.4TB, NVMe, 2.5″, mixed use | FusionServer V7–V8 | Look up → |
| 040 | 0255YBUP | 6.4TB, NVMe, 3.5″, mixed use | FusionServer V7–V8 | Look up → |
| 041 | 0255YCAX | 6.4TB, NVMe, 3.5″, mixed use | FusionServer V6 | Look up → |
| 042 | 0255YCHA | 6.4TB, NVMe, 2.5″, mixed use | FusionServer V7 | Look up → |
| 043 | 0255YCHB | 6.4TB, NVMe, 3.5″, mixed use | FusionServer V7 | Look up → |
| 044 | 0255YCTY | 6.4TB, NVMe PCIe 5.0, 3.5″, read intensive | FusionServer V8 | Look up → |
| 045 | 0255YCUD | 6.4TB, NVMe PCIe 5.0, 2.5″, mixed use | FusionServer V8 | Look up → |
| 046 | 0255YDCX | 6.4TB, NVMe PCIe 5.0, 3.5″, mixed use | FusionServer V7 | Look up → |
| 047 | 0255YDDD | 6.4TB, NVMe, 3.5″, mixed use | FusionServer V7 | Look up → |
| 048 | 0255YDHA | 6.4TB, NVMe, 2.5″, mixed use | FusionServer V8 | Look up → |
| 049 | 0255YDKQ | 6.4TB, NVMe PCIe 5.0, 3.5″, mixed use | FusionServer V6 | Look up → |
| 050 | 0255YEBN | 6.4TB, NVMe PCIe 5.0, 3.5″, mixed use | FusionServer V8 | Look up → |
| 051 | 0255YEBP | 6.4TB, NVMe PCIe 5.0, 2.5″, mixed use | FusionServer V8 | Look up → |
Not sure which of these fits your server? Check the xFusion compatibility center by model and ESN, or send us any part number for an exact match.
NVMe SSD 7.68TB — 87 official part numbers (V5–V8)
| # | Part number | Specification | Compatibility | Look up |
|---|---|---|---|---|
| 001 | 02312TBQ | 7.68TB, NVMe, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 002 | 02312WFM | 7.68TB, NVMe, 2.5″, read intensive | FusionServer V6 | Look up → |
| 003 | 02312WFN | 7.68TB, NVMe, 3.5″, read intensive | FusionServer V6 | Look up → |
| 004 | 0255Y031 | 7.68TB, NVMe, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 005 | 0255Y032 | 7.68TB, NVMe, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 006 | 0255Y065 | 7.68TB, NVMe, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 007 | 0255Y066 | 7.68TB, NVMe, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 008 | 0255Y067 | 7.68TB, NVMe, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 009 | 0255Y068 | 7.68TB, NVMe, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 010 | 0255Y145 | 7.68TB, NVMe, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 011 | 0255Y146 | 7.68TB, NVMe, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 012 | 0255Y186 | 7.68TB, NVMe, 2.5″, read intensive | FusionServer V6 | Look up → |
| 013 | 0255Y217 | 7.68TB, NVMe, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 014 | 0255Y305 | 7.68TB, NVMe, 2.5″, read intensive | FusionServer V7–V8 | Look up → |
| 015 | 0255Y306 | 7.68TB, NVMe, 3.5″, read intensive | FusionServer V6–V8 | Look up → |
| 016 | 0255Y319 | 7.68TB, NVMe, 2.5″, read intensive | FusionServer V6 | Look up → |
| 017 | 0255Y341 | 7.68TB, NVMe, 2.5″, read intensive | FusionServer V7 | Look up → |
| 018 | 0255Y342 | 7.68TB, NVMe, 3.5″, read intensive | FusionServer V7 | Look up → |
| 019 | 0255Y362 | 7.68TB, NVMe, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 020 | 0255Y395 | 7.68TB, NVMe, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 021 | 0255Y396 | 7.68TB, NVMe, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 022 | 0255Y468 | 7.68TB, NVMe, 2.5″, read intensive | FusionServer V7 | Look up → |
| 023 | 0255Y469 | 7.68TB, NVMe, 3.5″, read intensive | FusionServer V6–V7 | Look up → |
| 024 | 0255Y483 | 7.68TB, NVMe, 2.5″, read intensive | FusionServer V6 | Look up → |
| 025 | 0255Y519 | 7.68TB, NVMe, 2.5″, read intensive | FusionServer V5–V8 | Look up → |
| 026 | 0255Y520 | 7.68TB, NVMe, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 027 | 0255Y620 | 7.68TB, NVMe, 2.5″, read intensive | FusionServer V7 | Look up → |
| 028 | 0255Y621 | 7.68TB, NVMe, 3.5″, read intensive | FusionServer V7 | Look up → |
| 029 | 0255Y646 | 7.68TB, NVMe, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 030 | 0255Y647 | 7.68TB, NVMe, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 031 | 0255Y669 | 7.68TB, NVMe, 2.5″, read intensive | FusionServer V6 | Look up → |
| 032 | 0255Y680 | 7.68TB, NVMe, 2.5″, read intensive | FusionServer V6 | Look up → |
| 033 | 0255Y681 | 7.68TB, NVMe, 3.5″, read intensive | FusionServer V6 | Look up → |
| 034 | 0255Y899 | 7.68TB, NVMe, 2.5″, read intensive | FusionServer V7 | Look up → |
| 035 | 0255Y900 | 7.68TB, NVMe, 3.5″, read intensive | FusionServer V6–V7 | Look up → |
| 036 | 0255Y918 | 7.68TB, NVMe, 2.5″, read intensive | FusionServer V7 | Look up → |
| 037 | 0255Y973 | 7.68TB, NVMe, 2.5″, read intensive | FusionServer V7 | Look up → |
| 038 | 0255YABG | 7.68TB, NVMe, 2.5″, read intensive | FusionServer V6 | Look up → |
| 039 | 0255YABK | 7.68TB, NVMe, 2.5″, read intensive | FusionServer V7–V8 | Look up → |
| 040 | 0255YABS | 7.68TB, NVMe, 2.5″, read intensive | FusionServer V6 | Look up → |
| 041 | 0255YABT | 7.68TB, NVMe, 3.5″, read intensive | FusionServer V6 | Look up → |
| 042 | 0255YAEV | 7.68TB, NVMe, 2.5″, read intensive | FusionServer V7 | Look up → |
| 043 | 0255YAEW | 7.68TB, NVMe, 3.5″, read intensive | FusionServer V7 | Look up → |
| 044 | 0255YAEX | 7.68TB, NVMe PCIe 4.0, 2.5″, read intensive | FusionServer V7 | Look up → |
| 045 | 0255YAFG | 7.68TB, NVMe, 3.5″, read intensive | FusionServer V6 | Look up → |
| 046 | 0255YAFM | 7.68TB, NVMe, 2.5″, read intensive | FusionServer V7 | Look up → |
| 047 | 0255YAKB | 7.68TB, NVMe, 2.5″, read intensive | FusionServer V7 | Look up → |
| 048 | 0255YAKC | 7.68TB, NVMe PCIe 4.0, 3.5″, read intensive | FusionServer V7 | Look up → |
| 049 | 0255YAKL | 7.68TB, NVMe, 2.5″, read intensive | FusionServer V7 | Look up → |
| 050 | 0255YAPB | 7.68TB, NVMe, 2.5″, read intensive | FusionServer V7 | Look up → |
| 051 | 0255YARV | 7.68TB, NVMe, 3.5″, read intensive | FusionServer V7–V8 | Look up → |
| 052 | 0255YASD | 7.68TB, NVMe, 2.5″, read intensive | FusionServer V7 | Look up → |
| 053 | 0255YASE | 7.68TB, NVMe, 2.5″, read intensive | FusionServer V6 | Look up → |
| 054 | 0255YATJ | 7.68TB, NVMe PCIe 4.0, 2.5″, read intensive | FusionServer V6 | Look up → |
| 055 | 0255YBAL | 7.68TB, NVMe, 2.5″, read intensive | FusionServer V6 | Look up → |
| 056 | 0255YBAM | 7.68TB, NVMe, 3.5″, read intensive | FusionServer V6 | Look up → |
| 057 | 0255YBAS | 7.68TB, NVMe, 2.5″, read intensive | FusionServer V7–V8 | Look up → |
| 058 | 0255YBAT | 7.68TB, NVMe, 3.5″, read intensive | FusionServer V7–V8 | Look up → |
| 059 | 0255YBBF | 7.68TB, NVMe, 2.5″, read intensive | FusionServer V7–V8 | Look up → |
| 060 | 0255YBVH | 7.68TB, NVMe, 2.5″, read intensive | FusionServer V7 | Look up → |
| 061 | 0255YBVJ | 7.68TB, NVMe, 3.5″, read intensive | FusionServer V7 | Look up → |
| 062 | 0255YBVR | 7.68TB, NVMe, 2.5″, read intensive | FusionServer V6 | Look up → |
| 063 | 0255YBVS | 7.68TB, NVMe, 3.5″, read intensive | FusionServer V6 | Look up → |
| 064 | 0255YCHJ | 7.68TB, NVMe, 2.5″, read intensive | FusionServer V7 | Look up → |
| 065 | 0255YCHK | 7.68TB, NVMe, 3.5″, read intensive | FusionServer V7 | Look up → |
| 066 | 0255YCHL | 7.68TB, NVMe, 2.5″, read intensive | FusionServer V7 | Look up → |
| 067 | 0255YCHM | 7.68TB, NVMe, 3.5″, read intensive | FusionServer V7 | Look up → |
| 068 | 0255YCHN | 7.68TB, NVMe, 2.5″, read intensive | FusionServer V7 | Look up → |
| 069 | 0255YCHP | 7.68TB, NVMe, 3.5″, read intensive | FusionServer V7 | Look up → |
| 070 | 0255YCKM | 7.68TB, NVMe, 2.5″, read intensive | FusionServer V6 | Look up → |
| 071 | 0255YCKN | 7.68TB, NVMe, 2.5″, read intensive | FusionServer V7 | Look up → |
| 072 | 0255YCMF | 7.68TB, NVMe, 2.5″, read intensive | FusionServer V7 | Look up → |
| 073 | 0255YCQP | 7.68TB, NVMe PCIe 5.0, 2.5″, read intensive | FusionServer V7 | Look up → |
| 074 | 0255YCUA | 7.68TB, NVMe PCIe 5.0, 3.5″, read intensive | FusionServer V8 | Look up → |
| 075 | 0255YCUE | 7.68TB, NVMe PCIe 5.0, 2.5″, read intensive | FusionServer V8 | Look up → |
| 076 | 0255YDAV | 7.68TB, NVMe, 2.5″, read intensive | FusionServer V7 | Look up → |
| 077 | 0255YDNX | 7.68TB, NVMe PCIe 5.0, 2.5″, read intensive | FusionServer V7 | Look up → |
| 078 | 0255YDPA | 7.68TB, NVMe PCIe 5.0, 2.5″, read intensive | FusionServer V7 | Look up → |
| 079 | 0255YDPC | 7.68TB, NVMe, 3.5″, read intensive | FusionServer V7 | Look up → |
| 080 | 0255YDSA | 7.68TB, NVMe, 2.5″, read intensive | FusionServer V7 | Look up → |
| 081 | 0255YDXV | 7.68TB, NVMe PCIe 5.0, 2.5″, read intensive | FusionServer V8 | Look up → |
| 082 | 0255YDXW | 7.68TB, NVMe PCIe 5.0, 3.5″, read intensive | FusionServer V8 | Look up → |
| 083 | 0255YEBL | 7.68TB, NVMe, 2.5″, read intensive | FusionServer V7 | Look up → |
| 084 | 0255YECB | 7.68TB, NVMe, 2.5″, read intensive | FusionServer V7 | Look up → |
| 085 | 0255YENR | 7.68TB, NVMe PCIe 4.0, 2.5″, mixed use | FusionServer V7 | Look up → |
| 086 | 0255YENS | 7.68TB, NVMe PCIe 4.0, 2.5″, mixed use | FusionServer V7 | Look up → |
| 087 | 0255YFHJ | 7.68TB, NVMe PCIe 5.0, E3.S, read intensive | FusionServer V8 | Look up → |
Not sure which of these fits your server? Check the xFusion compatibility center by model and ESN, or send us any part number for an exact match.
NVMe SSD 8TB — 2 official part numbers (V5–V6)
| # | Part number | Specification | Compatibility | Look up |
|---|---|---|---|---|
| 001 | 02312HER | 8TB, NVMe, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 002 | 02312HES | 8TB, NVMe, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
Not sure which of these fits your server? Check the xFusion compatibility center by model and ESN, or send us any part number for an exact match.
NVMe SSD 12.8TB — 4 official part numbers (V7–V8)
| # | Part number | Specification | Compatibility | Look up |
|---|---|---|---|---|
| 001 | 0255YBTU | 12.8TB, NVMe, 2.5″, read intensive | FusionServer V7 | Look up → |
| 002 | 0255YCSD | 12.8TB, NVMe, 2.5″, mixed use | FusionServer V7 | Look up → |
| 003 | 0255YEDM | 12.8TB, NVMe PCIe 5.0, 2.5″, mixed use | FusionServer V8 | Look up → |
| 004 | 0255YEDN | 12.8TB, NVMe PCIe 5.0, 3.5″, mixed use | FusionServer V8 | Look up → |
Not sure which of these fits your server? Check the xFusion compatibility center by model and ESN, or send us any part number for an exact match.
NVMe SSD 15.36TB — 11 official part numbers (V5–V8)
| # | Part number | Specification | Compatibility | Look up |
|---|---|---|---|---|
| 001 | 0255Y073 | 15.36TB, NVMe, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 002 | 0255Y074 | 15.36TB, NVMe, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 003 | 0255Y920 | 15.36TB, NVMe, 2.5″, read intensive | FusionServer V7 | Look up → |
| 004 | 0255Y946 | 15.36TB, NVMe, 3.5″, read intensive | FusionServer V6–V7 | Look up → |
| 005 | 0255YATK | 15.36TB, NVMe PCIe 4.0, 2.5″, read intensive | FusionServer V6 | Look up → |
| 006 | 0255YCRX | 15.36TB, NVMe, 2.5″, read intensive | FusionServer V7–V8 | Look up → |
| 007 | 0255YCRY | 15.36TB, NVMe, 3.5″, read intensive | FusionServer V7–V8 | Look up → |
| 008 | 0255YDNP | 15.36TB, NVMe PCIe 5.0, 2.5″, read intensive | FusionServer V7 | Look up → |
| 009 | 0255YENE | 15.36TB, NVMe PCIe 5.0, 2.5″, read intensive | FusionServer V8 | Look up → |
| 010 | 0255YFFN | 15.36TB, NVMe PCIe 5.0, 2.5″, read intensive | FusionServer V8 | Look up → |
| 011 | 0255YFFS | 15.36TB, NVMe PCIe 5.0, 3.5″, read intensive | FusionServer V8 | Look up → |
Not sure which of these fits your server? Check the xFusion compatibility center by model and ESN, or send us any part number for an exact match.
NVMe SSD 61.44TB — 1 official part numbers (V8–V8)
| # | Part number | Specification | Compatibility | Look up |
|---|---|---|---|---|
| 001 | 0255YEFL | 61.44TB, NVMe PCIe 5.0, 2.5″, read intensive | FusionServer V8 | Look up → |
Not sure which of these fits your server? Check the xFusion compatibility center by model and ESN, or send us any part number for an exact match.
SAS SSD 600GB — 13 official part numbers (V5–V8)
| # | Part number | Specification | Compatibility | Look up |
|---|---|---|---|---|
| 001 | 02312RBW | 600GB, SAS, 2.5″, 10000 RPM | FusionServer V5–V6 | Look up → |
| 002 | 02540033 | 600GB, SAS, 2.5″, 10000 RPM | FusionServer V6 | Look up → |
| 003 | 02540040 | 600GB, SAS, 3.5″, 10000 RPM | FusionServer V6 | Look up → |
| 004 | 0254Y057 | 600GB, SAS, 2.5″, 10000 RPM | FusionServer V7–V8 | Look up → |
| 005 | 0254Y058 | 600GB, SAS, 3.5″, 10000 RPM | FusionServer V6–V8 | Look up → |
| 006 | 0254Y077 | 600GB, SAS, 2.5″, 10000 RPM | FusionServer V6 | Look up → |
| 007 | 0254Y078 | 600GB, SAS, 3.5″, 10000 RPM | FusionServer V6 | Look up → |
| 008 | 0254Y369 | 600GB, SAS, 2.5″, 10000 RPM | FusionServer V7–V8 | Look up → |
| 009 | 0254Y370 | 600GB, SAS, 2.5″, 10000 RPM | FusionServer V7–V8 | Look up → |
| 010 | 0254Y700 | 600GB, SAS, 3.5″, 10000 RPM | FusionServer V6–V8 | Look up → |
| 011 | 0254Y702 | 600GB, SAS, 3.5″, 10000 RPM | FusionServer V6–V8 | Look up → |
| 012 | 0254Y716 | 600GB, SAS, 2.5″, 10000 RPM | FusionServer V6 | Look up → |
| 013 | 0254Y717 | 600GB, SAS, 3.5″, 10000 RPM | FusionServer V6 | Look up → |
Not sure which of these fits your server? Check the xFusion compatibility center by model and ESN, or send us any part number for an exact match.
SAS SSD 800GB — 2 official part numbers (V5–V6)
| # | Part number | Specification | Compatibility | Look up |
|---|---|---|---|---|
| 001 | 02313FSF | 800GB, SAS, 2.5″, mixed use | FusionServer V5–V6 | Look up → |
| 002 | 02313FSG | 800GB, SAS, 3.5″, mixed use | FusionServer V5–V6 | Look up → |
Not sure which of these fits your server? Check the xFusion compatibility center by model and ESN, or send us any part number for an exact match.
SAS SSD 960GB — 19 official part numbers (V5–V7)
| # | Part number | Specification | Compatibility | Look up |
|---|---|---|---|---|
| 001 | 02313ELL | 960GB, SAS, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 002 | 02313ELP | 960GB, SAS, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 003 | 02313FRT | 960GB, SAS, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 004 | 02313FRU | 960GB, SAS, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 005 | 0255Y071 | 960GB, SAS, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 006 | 0255Y072 | 960GB, SAS, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 007 | 0255Y174 | 960GB, SAS, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 008 | 0255Y175 | 960GB, SAS, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 009 | 0255Y458 | 960GB, SAS, 2.5″, read intensive | FusionServer V7 | Look up → |
| 010 | 0255Y459 | 960GB, SAS, 3.5″, read intensive | FusionServer V6 | Look up → |
| 011 | 0255Y812 | 960GB, SAS, 2.5″, read intensive | FusionServer V6 | Look up → |
| 012 | 0255Y841 | 960GB, SAS, 3.5″, read intensive | FusionServer V6 | Look up → |
| 013 | 0255Y960 | 960GB, SAS, 2.5″, read intensive | FusionServer V6 | Look up → |
| 014 | 0255Y961 | 960GB, SAS, 3.5″, read intensive | FusionServer V6 | Look up → |
| 015 | 0255Y998 | 960GB, SAS, 2.5″, read intensive | FusionServer V7 | Look up → |
| 016 | 0255Y999 | 960GB, SAS, 3.5″, read intensive | FusionServer V6 | Look up → |
| 017 | 0255YAAX | 960GB, SAS, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 018 | 0255YAAY | 960GB, SAS, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 019 | 0255YBLJ | 960GB, SAS, 2.5″, read intensive | FusionServer V7 | Look up → |
Not sure which of these fits your server? Check the xFusion compatibility center by model and ESN, or send us any part number for an exact match.
SAS SSD 1.2TB — 19 official part numbers (V5–V8)
| # | Part number | Specification | Compatibility | Look up |
|---|---|---|---|---|
| 001 | 02312RBV | 1.2TB, SAS, 2.5″, 10000 RPM | FusionServer V5–V6 | Look up → |
| 002 | 02540015 | 1.2TB, SAS, 2.5″, 10000 RPM | FusionServer V5–V6 | Look up → |
| 003 | 02540016 | 1.2TB, SAS, 3.5″, 10000 RPM | FusionServer V5–V6 | Look up → |
| 004 | 02540034 | 1.2TB, SAS, 2.5″, 10000 RPM | FusionServer V6 | Look up → |
| 005 | 02540039 | 1.2TB, SAS, 3.5″, 10000 RPM | FusionServer V6 | Look up → |
| 006 | 0254Y059 | 1.2TB, SAS, 2.5″, 10000 RPM | FusionServer V7–V8 | Look up → |
| 007 | 0254Y060 | 1.2TB, SAS, 3.5″, 10000 RPM | FusionServer V6–V8 | Look up → |
| 008 | 0254Y177 | 1.2TB, SAS, 2.5″, 10000 RPM | FusionServer V6 | Look up → |
| 009 | 0254Y178 | 1.2TB, SAS, 3.5″, 10000 RPM | FusionServer V6 | Look up → |
| 010 | 0254Y208 | 1.2TB, SAS, 2.5″, 10000 RPM | FusionServer V6 | Look up → |
| 011 | 0254Y209 | 1.2TB, SAS, 3.5″, 10000 RPM | FusionServer V6 | Look up → |
| 012 | 0254Y291 | 1.2TB, SAS, 2.5″, 10000 RPM | FusionServer V6 | Look up → |
| 013 | 0254Y292 | 1.2TB, SAS, 3.5″, 10000 RPM | FusionServer V6 | Look up → |
| 014 | 0254Y708 | 1.2TB, SAS, 3.5″, 10000 RPM | FusionServer V6–V7 | Look up → |
| 015 | 0254Y709 | 1.2TB, SAS, 3.5″, 10000 RPM | FusionServer V6–V7 | Look up → |
| 016 | 0254Y710 | 1.2TB, SAS, 2.5″, 10000 RPM | FusionServer V7 | Look up → |
| 017 | 0254Y711 | 1.2TB, SAS, 2.5″, 10000 RPM | FusionServer V7 | Look up → |
| 018 | 0254Y718 | 1.2TB, SAS, 2.5″, 10000 RPM | FusionServer V6 | Look up → |
| 019 | 0254Y719 | 1.2TB, SAS, 3.5″, 10000 RPM | FusionServer V6 | Look up → |
Not sure which of these fits your server? Check the xFusion compatibility center by model and ESN, or send us any part number for an exact match.
SAS SSD 1.6TB — 11 official part numbers (V5–V7)
| # | Part number | Specification | Compatibility | Look up |
|---|---|---|---|---|
| 001 | 02313FSJ | 1.6TB, SAS, 2.5″, mixed use | FusionServer V5–V6 | Look up → |
| 002 | 02313FSK | 1.6TB, SAS, 3.5″, mixed use | FusionServer V5–V6 | Look up → |
| 003 | 02550229 | 1.6TB, SAS, 2.5″, mixed use | FusionServer V5–V6 | Look up → |
| 004 | 02550232 | 1.6TB, SAS, 3.5″, mixed use | FusionServer V5–V6 | Look up → |
| 005 | 0255Y944 | 1.6TB, SAS, 2.5″, mixed use | FusionServer V7 | Look up → |
| 006 | 0255Y945 | 1.6TB, SAS, 3.5″, mixed use | FusionServer V7 | Look up → |
| 007 | 0255YCDF | 1.6TB, SAS, 2.5″, mixed use | FusionServer V6 | Look up → |
| 008 | 0255YCDG | 1.6TB, SAS, 3.5″, mixed use | FusionServer V6 | Look up → |
| 009 | 0255YCDN | 1.6TB, SAS, 2.5″, mixed use | FusionServer V7 | Look up → |
| 010 | 0255YCDP | 1.6TB, SAS, 3.5″, mixed use | FusionServer V7 | Look up → |
| 011 | 0255YEDH | 1.6TB, SAS, 2.5″, mixed use | FusionServer V7 | Look up → |
Not sure which of these fits your server? Check the xFusion compatibility center by model and ESN, or send us any part number for an exact match.
SAS SSD 1.8TB — 13 official part numbers (V5–V7)
| # | Part number | Specification | Compatibility | Look up |
|---|---|---|---|---|
| 001 | 02312RBS | 1.8TB, SAS, 2.5″, 10000 RPM | FusionServer V5–V6 | Look up → |
| 002 | 02540035 | 1.8TB, SAS, 2.5″, 10000 RPM | FusionServer V6 | Look up → |
| 003 | 02540038 | 1.8TB, SAS, 3.5″, 10000 RPM | FusionServer V6 | Look up → |
| 004 | 0254Y061 | 1.8TB, SAS, 2.5″, 10000 RPM | FusionServer V7 | Look up → |
| 005 | 0254Y062 | 1.8TB, SAS, 3.5″, 10000 RPM | FusionServer V6–V7 | Look up → |
| 006 | 0254Y111 | 1.8TB, SAS, 2.5″, 10000 RPM | FusionServer V6 | Look up → |
| 007 | 0254Y114 | 1.8TB, SAS, 3.5″, 10000 RPM | FusionServer V6 | Look up → |
| 008 | 0254Y189 | 1.8TB, SAS, 2.5″, 10000 RPM | FusionServer V6 | Look up → |
| 009 | 0254Y190 | 1.8TB, SAS, 3.5″, 10000 RPM | FusionServer V6 | Look up → |
| 010 | 0254Y712 | 1.8TB, SAS, 3.5″, 10000 RPM | FusionServer V6–V7 | Look up → |
| 011 | 0254Y713 | 1.8TB, SAS, 3.5″, 10000 RPM | FusionServer V6–V7 | Look up → |
| 012 | 0254Y714 | 1.8TB, SAS, 2.5″, 10000 RPM | FusionServer V7 | Look up → |
| 013 | 0254Y715 | 1.8TB, SAS, 2.5″, 10000 RPM | FusionServer V7 | Look up → |
Not sure which of these fits your server? Check the xFusion compatibility center by model and ESN, or send us any part number for an exact match.
SAS SSD 1.92TB — 18 official part numbers (V5–V7)
| # | Part number | Specification | Compatibility | Look up |
|---|---|---|---|---|
| 001 | 02313ELY | 1.92TB, SAS, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 002 | 02313EMA | 1.92TB, SAS, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 003 | 02313FRV | 1.92TB, SAS, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 004 | 02313FRW | 1.92TB, SAS, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 005 | 02550222 | 1.92TB, SAS, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 006 | 02550226 | 1.92TB, SAS, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 007 | 0255Y157 | 1.92TB, SAS, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 008 | 0255Y158 | 1.92TB, SAS, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 009 | 0255Y207 | 1.92TB, SAS, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 010 | 0255Y208 | 1.92TB, SAS, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 011 | 0255Y460 | 1.92TB, SAS, 2.5″, read intensive | FusionServer V7 | Look up → |
| 012 | 0255Y813 | 1.92TB, SAS, 2.5″, read intensive | FusionServer V6 | Look up → |
| 013 | 0255YAAA | 1.92TB, SAS, 2.5″, read intensive | FusionServer V7 | Look up → |
| 014 | 0255YABA | 1.92TB, SAS, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 015 | 0255YABB | 1.92TB, SAS, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 016 | 0255YBLG | 1.92TB, SAS, 2.5″, read intensive | FusionServer V7 | Look up → |
| 017 | 0255YCEE | 1.92TB, SAS, 2.5″, read intensive | FusionServer V7 | Look up → |
| 018 | 0255YCEG | 1.92TB, SAS, 3.5″, read intensive | FusionServer V7 | Look up → |
Not sure which of these fits your server? Check the xFusion compatibility center by model and ESN, or send us any part number for an exact match.
SAS SSD 2.4TB — 20 official part numbers (V5–V8)
| # | Part number | Specification | Compatibility | Look up |
|---|---|---|---|---|
| 001 | 02312RCM | 2.4TB, SAS, 2.5″ | FusionServer V5–V6 | Look up → |
| 002 | 02540036 | 2.4TB, SAS, 2.5″, 10000 RPM | FusionServer V6 | Look up → |
| 003 | 02540037 | 2.4TB, SAS, 3.5″, 10000 RPM | FusionServer V6 | Look up → |
| 004 | 0254Y063 | 2.4TB, SAS, 2.5″, 10000 RPM | FusionServer V7–V8 | Look up → |
| 005 | 0254Y064 | 2.4TB, SAS, 3.5″, 10000 RPM | FusionServer V6–V8 | Look up → |
| 006 | 0254Y163 | 2.4TB, SAS, 2.5″, 10000 RPM | FusionServer V6 | Look up → |
| 007 | 0254Y164 | 2.4TB, SAS, 3.5″, 10000 RPM | FusionServer V6 | Look up → |
| 008 | 0254Y165 | 2.4TB, SAS, 2.5″, 10000 RPM | FusionServer V6 | Look up → |
| 009 | 0254Y166 | 2.4TB, SAS, 3.5″, 10000 RPM | FusionServer V6 | Look up → |
| 010 | 0254Y179 | 2.4TB, SAS, 2.5″, 10000 RPM | FusionServer V6 | Look up → |
| 011 | 0254Y180 | 2.4TB, SAS, 3.5″, 10000 RPM | FusionServer V6 | Look up → |
| 012 | 0254Y298 | 2.4TB, SAS, 2.5″, 10000 RPM | FusionServer V6 | Look up → |
| 013 | 0254Y356 | 2.4TB, SAS, 2.5″, 10000 RPM | FusionServer V7 | Look up → |
| 014 | 0254Y357 | 2.4TB, SAS, 3.5″, 10000 RPM | FusionServer V6–V7 | Look up → |
| 015 | 0254Y358 | 2.4TB, SAS, 2.5″, 10000 RPM | FusionServer V7 | Look up → |
| 016 | 0254Y359 | 2.4TB, SAS, 3.5″, 10000 RPM | FusionServer V6–V7 | Look up → |
| 017 | 0254Y477 | 2.4TB, SAS, 2.5″, 10000 RPM | FusionServer V7 | Look up → |
| 018 | 0254Y478 | 2.4TB, SAS, 3.5″, 10000 RPM | FusionServer V7 | Look up → |
| 019 | 0254Y479 | 2.4TB, SAS, 2.5″, 10000 RPM | FusionServer V7 | Look up → |
| 020 | 0254Y480 | 2.4TB, SAS, 3.5″, 10000 RPM | FusionServer V7 | Look up → |
Not sure which of these fits your server? Check the xFusion compatibility center by model and ESN, or send us any part number for an exact match.
SAS SSD 3.2TB — 15 official part numbers (V5–V7)
| # | Part number | Specification | Compatibility | Look up |
|---|---|---|---|---|
| 001 | 02313FSL | 3.2TB, SAS, 2.5″, mixed use | FusionServer V5–V6 | Look up → |
| 002 | 02313FSR | 3.2TB, SAS, 3.5″, mixed use | FusionServer V5–V6 | Look up → |
| 003 | 02550230 | 3.2TB, SAS, 2.5″, mixed use | FusionServer V5–V6 | Look up → |
| 004 | 02550233 | 3.2TB, SAS, 3.5″, mixed use | FusionServer V5–V6 | Look up → |
| 005 | 0255Y163 | 3.2TB, SAS, 2.5″, mixed use | FusionServer V5–V6 | Look up → |
| 006 | 0255Y164 | 3.2TB, SAS, 3.5″, mixed use | FusionServer V5–V6 | Look up → |
| 007 | 0255Y165 | 3.2TB, SAS, 2.5″, mixed use | FusionServer V5–V6 | Look up → |
| 008 | 0255Y166 | 3.2TB, SAS, 3.5″, mixed use | FusionServer V5–V6 | Look up → |
| 009 | 0255Y209 | 3.2TB, SAS, 2.5″, mixed use | FusionServer V5–V6 | Look up → |
| 010 | 0255Y210 | 3.2TB, SAS, 3.5″, mixed use | FusionServer V5–V6 | Look up → |
| 011 | 0255YABC | 3.2TB, SAS, 2.5″, mixed use | FusionServer V5–V6 | Look up → |
| 012 | 0255YABD | 3.2TB, SAS, 3.5″, mixed use | FusionServer V6 | Look up → |
| 013 | 0255YCDQ | 3.2TB, SAS, 2.5″, mixed use | FusionServer V7 | Look up → |
| 014 | 0255YCDR | 3.2TB, SAS, 3.5″, mixed use | FusionServer V7 | Look up → |
| 015 | 0255YEDJ | 3.2TB, SAS, 2.5″, mixed use | FusionServer V7 | Look up → |
Not sure which of these fits your server? Check the xFusion compatibility center by model and ESN, or send us any part number for an exact match.
SAS SSD 3.84TB — 23 official part numbers (V5–V7)
| # | Part number | Specification | Compatibility | Look up |
|---|---|---|---|---|
| 001 | 02313EMB | 3.84TB, SAS, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 002 | 02313EMC | 3.84TB, SAS, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 003 | 02313FSB | 3.84TB, SAS, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 004 | 02313FSC | 3.84TB, SAS, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 005 | 02550224 | 3.84TB, SAS, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 006 | 02550225 | 3.84TB, SAS, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 007 | 0255Y153 | 3.84TB, SAS, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 008 | 0255Y154 | 3.84TB, SAS, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 009 | 0255Y159 | 3.84TB, SAS, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 010 | 0255Y160 | 3.84TB, SAS, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 011 | 0255Y176 | 3.84TB, SAS, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 012 | 0255Y177 | 3.84TB, SAS, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 013 | 0255Y462 | 3.84TB, SAS, 2.5″, read intensive | FusionServer V7 | Look up → |
| 014 | 0255Y814 | 3.84TB, SAS, 2.5″, read intensive | FusionServer V6 | Look up → |
| 015 | 0255Y964 | 3.84TB, SAS, 2.5″, read intensive | FusionServer V6 | Look up → |
| 016 | 0255YAAC | 3.84TB, SAS, 2.5″, read intensive | FusionServer V7 | Look up → |
| 017 | 0255YAAD | 3.84TB, SAS, 3.5″, read intensive | FusionServer V6 | Look up → |
| 018 | 0255YAAV | 3.84TB, SAS, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 019 | 0255YAAW | 3.84TB, SAS, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 020 | 0255YBLD | 3.84TB, SAS, 2.5″, read intensive | FusionServer V7 | Look up → |
| 021 | 0255YBME | 3.84TB, SAS, 2.5″, read intensive | FusionServer V7 | Look up → |
| 022 | 0255YCEH | 3.84TB, SAS, 2.5″, read intensive | FusionServer V7 | Look up → |
| 023 | 0255YCEJ | 3.84TB, SAS, 3.5″, read intensive | FusionServer V7 | Look up → |
Not sure which of these fits your server? Check the xFusion compatibility center by model and ESN, or send us any part number for an exact match.
SAS SSD 4TB — 1 official part numbers (V5–V6)
| # | Part number | Specification | Compatibility | Look up |
|---|---|---|---|---|
| 001 | 0254Y010 | 4TB, SAS, 3.5″, 7200 RPM | FusionServer V5–V6 | Look up → |
Not sure which of these fits your server? Check the xFusion compatibility center by model and ESN, or send us any part number for an exact match.
SAS SSD 6TB — 1 official part numbers (V5–V6)
| # | Part number | Specification | Compatibility | Look up |
|---|---|---|---|---|
| 001 | 0254Y011 | 6TB, SAS, 3.5″, 7200 RPM | FusionServer V5–V6 | Look up → |
Not sure which of these fits your server? Check the xFusion compatibility center by model and ESN, or send us any part number for an exact match.
SAS SSD 6.4TB — 8 official part numbers (V5–V7)
| # | Part number | Specification | Compatibility | Look up |
|---|---|---|---|---|
| 001 | 02313FSS | 6.4TB, SAS, 2.5″, mixed use | FusionServer V5–V6 | Look up → |
| 002 | 02313FSV | 6.4TB, SAS, 3.5″, mixed use | FusionServer V5–V6 | Look up → |
| 003 | 02550231 | 6.4TB, SAS, 2.5″, mixed use | FusionServer V5–V6 | Look up → |
| 004 | 02550234 | 6.4TB, SAS, 3.5″, mixed use | FusionServer V5–V6 | Look up → |
| 005 | 0255YCDL | 6.4TB, SAS, 2.5″, mixed use | FusionServer V6 | Look up → |
| 006 | 0255YCDM | 6.4TB, SAS, 3.5″, mixed use | FusionServer V6 | Look up → |
| 007 | 0255YCDS | 6.4TB, SAS, 2.5″, mixed use | FusionServer V7 | Look up → |
| 008 | 0255YCDT | 6.4TB, SAS, 3.5″, mixed use | FusionServer V7 | Look up → |
Not sure which of these fits your server? Check the xFusion compatibility center by model and ESN, or send us any part number for an exact match.
SAS SSD 7.68TB — 14 official part numbers (V5–V7)
| # | Part number | Specification | Compatibility | Look up |
|---|---|---|---|---|
| 001 | 02313EMD | 7.68TB, SAS, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 002 | 02313EME | 7.68TB, SAS, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 003 | 02313FSD | 7.68TB, SAS, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 004 | 02313FSE | 7.68TB, SAS, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 005 | 02550227 | 7.68TB, SAS, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 006 | 02550228 | 7.68TB, SAS, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 007 | 0255Y161 | 7.68TB, SAS, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 008 | 0255Y162 | 7.68TB, SAS, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 009 | 0255Y815 | 7.68TB, SAS, 2.5″, read intensive | FusionServer V6 | Look up → |
| 010 | 0255Y966 | 7.68TB, SAS, 2.5″, read intensive | FusionServer V6 | Look up → |
| 011 | 0255YAUY | 7.68TB, SAS, 2.5″, read intensive | FusionServer V7 | Look up → |
| 012 | 0255YBLB | 7.68TB, SAS, 2.5″, read intensive | FusionServer V7 | Look up → |
| 013 | 0255YCEK | 7.68TB, SAS, 2.5″, read intensive | FusionServer V7 | Look up → |
| 014 | 0255YCEL | 7.68TB, SAS, 3.5″, read intensive | FusionServer V7 | Look up → |
Not sure which of these fits your server? Check the xFusion compatibility center by model and ESN, or send us any part number for an exact match.
SAS SSD 8TB — 3 official part numbers (V5–V6)
| # | Part number | Specification | Compatibility | Look up |
|---|---|---|---|---|
| 001 | 0254Y012 | 8TB, SAS, 3.5″, 7200 RPM | FusionServer V5–V6 | Look up → |
| 002 | 0254Y182 | 8TB, SAS, 3.5″, 7200 RPM | FusionServer V6 | Look up → |
| 003 | 0254Y215 | 8TB, SAS, 3.5″, 7200 RPM | FusionServer V6 | Look up → |
Not sure which of these fits your server? Check the xFusion compatibility center by model and ESN, or send us any part number for an exact match.
SAS SSD 10TB — 1 official part numbers (V6–V6)
| # | Part number | Specification | Compatibility | Look up |
|---|---|---|---|---|
| 001 | 0254Y084 | 10TB, SAS, 3.5″, 7200 RPM | FusionServer V6 | Look up → |
Not sure which of these fits your server? Check the xFusion compatibility center by model and ESN, or send us any part number for an exact match.
SAS SSD 12TB — 1 official part numbers (V7–V7)
| # | Part number | Specification | Compatibility | Look up |
|---|---|---|---|---|
| 001 | 0254Y948 | 12TB, SAS, 3.5″, 7200 RPM | FusionServer V7 | Look up → |
Not sure which of these fits your server? Check the xFusion compatibility center by model and ESN, or send us any part number for an exact match.
SAS SSD 15.36TB — 1 official part numbers (V6–V6)
| # | Part number | Specification | Compatibility | Look up |
|---|---|---|---|---|
| 001 | 0255YAKU | 15.36TB, SAS, 2.5″, read intensive | FusionServer V6 | Look up → |
Not sure which of these fits your server? Check the xFusion compatibility center by model and ESN, or send us any part number for an exact match.
SAS SSD 16TB — 2 official part numbers (V6–V7)
| # | Part number | Specification | Compatibility | Look up |
|---|---|---|---|---|
| 001 | 0254Y082 | 16TB, SAS, 3.5″, 7200 RPM | FusionServer V6 | Look up → |
| 002 | 0254Y949 | 16TB, SAS, 3.5″, 7200 RPM | FusionServer V7 | Look up → |
Not sure which of these fits your server? Check the xFusion compatibility center by model and ESN, or send us any part number for an exact match.
SAS SSD 20TB — 4 official part numbers (V7–V8)
| # | Part number | Specification | Compatibility | Look up |
|---|---|---|---|---|
| 001 | 0254Y243 | 20TB, SAS, 3.5″, 7200 RPM | FusionServer V7 | Look up → |
| 002 | 0254Y427 | 20TB, SAS, 3.5″, 7200 RPM | FusionServer V7 | Look up → |
| 003 | 0254Y888 | 20TB, SAS, 3.5″, 7200 RPM | FusionServer V7–V8 | Look up → |
| 004 | 0254Y950 | 20TB, SAS, 3.5″, 7200 RPM | FusionServer V7–V8 | Look up → |
Not sure which of these fits your server? Check the xFusion compatibility center by model and ESN, or send us any part number for an exact match.
SAS SSD 24TB — 1 official part numbers (V8–V8)
| # | Part number | Specification | Compatibility | Look up |
|---|---|---|---|---|
| 001 | 0254Y764 | 24TB, SAS, 3.5″, 7200 RPM | FusionServer V8 | Look up → |
Not sure which of these fits your server? Check the xFusion compatibility center by model and ESN, or send us any part number for an exact match.
SATA SSD 6GB — 20 official part numbers (V5–V8)
| # | Part number | Specification | Compatibility | Look up |
|---|---|---|---|---|
| 001 | 02312KGR | 6GB, SATA, M.2 | FusionServer V5–V6 | Look up → |
| 002 | 02313ARC | 6GB, SATA, M.2 | FusionServer V5–V6 | Look up → |
| 003 | 02313ARE | 6GB, SATA, M.2 | FusionServer V5–V7 | Look up → |
| 004 | 02313ARH | 6GB, SATA, M.2 | FusionServer V5–V6 | Look up → |
| 005 | 02313ARJ | 6GB, SATA, M.2 | FusionServer V6–V7 | Look up → |
| 006 | 02313EKD | 6GB, SATA, M.2 | FusionServer V5–V6 | Look up → |
| 007 | 02313FFY | 6GB, SATA, M.2 | FusionServer V6 | Look up → |
| 008 | 02313FNB | 6GB, SATA, M.2 | FusionServer V5–V6 | Look up → |
| 009 | 0255Y689 | 6GB, SATA, M.2 | FusionServer V6 | Look up → |
| 010 | 0255Y695 | 6GB, SATA, M.2 | FusionServer V5–V8 | Look up → |
| 011 | 0255Y696 | 6GB, SATA, M.2 | FusionServer V6–V8 | Look up → |
| 012 | 0255Y697 | 6GB, SATA, M.2 | FusionServer V5–V8 | Look up → |
| 013 | 0255Y698 | 6GB, SATA, M.2 | FusionServer V6–V8 | Look up → |
| 014 | 0255YAKY | 6GB, SATA, M.2 | FusionServer V8 | Look up → |
| 015 | 0255YCGB | 6GB, SATA, M.2 | FusionServer V7 | Look up → |
| 016 | 0255YCGE | 6GB, SATA, M.2 | FusionServer V7 | Look up → |
| 017 | 0255YCNW | 6GB, SATA, M.2 | FusionServer V7–V8 | Look up → |
| 018 | 0255YCTX | 6GB, SATA, M.2 | FusionServer V7–V8 | Look up → |
| 019 | 0255YDPD | 6GB, SATA, M.2 | FusionServer V7 | Look up → |
| 020 | 0255YDXH | 6GB, SATA, M.2 | FusionServer V7 | Look up → |
Not sure which of these fits your server? Check the xFusion compatibility center by model and ESN, or send us any part number for an exact match.
SATA SSD 240GB — 29 official part numbers (V5–V7)
| # | Part number | Specification | Compatibility | Look up |
|---|---|---|---|---|
| 001 | 02312GND | 240GB, SATA, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 002 | 02312GNE | 240GB, SATA, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 003 | 02312GNP | 240GB, SATA, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 004 | 02312GNQ | 240GB, SATA, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 005 | 02312GTJ | 240GB, SATA, 3.5″, mixed use | FusionServer V5–V6 | Look up → |
| 006 | 02312GTQ | 240GB, SATA, 2.5″, mixed use | FusionServer V5–V6 | Look up → |
| 007 | 02312GUA | 240GB, SATA, 2.5″, mixed use | FusionServer V5–V6 | Look up → |
| 008 | 02313DHR | 240GB, SATA, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 009 | 02313DHS | 240GB, SATA, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 010 | 02313EYY | 240GB, SATA, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 011 | 02313FAB | 240GB, SATA, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 012 | 0255Y014 | 240GB, SATA, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 013 | 0255Y015 | 240GB, SATA, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 014 | 0255Y051 | 240GB, SATA, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 015 | 0255Y078 | 240GB, SATA, 3.5″, read intensive | FusionServer V6 | Look up → |
| 016 | 0255Y105 | 240GB, SATA, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 017 | 0255Y106 | 240GB, SATA, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 018 | 0255Y199 | 240GB, SATA, 2.5″, read intensive | FusionServer V6 | Look up → |
| 019 | 0255Y397 | 240GB, SATA, 2.5″, read intensive | FusionServer V7 | Look up → |
| 020 | 0255Y398 | 240GB, SATA, 3.5″, read intensive | FusionServer V6–V7 | Look up → |
| 021 | 0255Y415 | 240GB, SATA, 2.5″, read intensive | FusionServer V7 | Look up → |
| 022 | 0255Y416 | 240GB, SATA, 3.5″, read intensive | FusionServer V7 | Look up → |
| 023 | 0255Y434 | 240GB, SATA, 2.5″, read intensive | FusionServer V7 | Look up → |
| 024 | 0255Y435 | 240GB, SATA, 3.5″, read intensive | FusionServer V7 | Look up → |
| 025 | 0255Y442 | 240GB, SATA, 2.5″, read intensive | FusionServer V7 | Look up → |
| 026 | 0255Y443 | 240GB, SATA, 3.5″, read intensive | FusionServer V7 | Look up → |
| 027 | 0255Y450 | 240GB, SATA, 2.5″, read intensive | FusionServer V7 | Look up → |
| 028 | 0255Y451 | 240GB, SATA, 3.5″, read intensive | FusionServer V6–V7 | Look up → |
| 029 | 0255Y638 | 240GB, SATA, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
Not sure which of these fits your server? Check the xFusion compatibility center by model and ESN, or send us any part number for an exact match.
SATA SSD 480GB — 91 official part numbers (V5–V8)
| # | Part number | Specification | Compatibility | Look up |
|---|---|---|---|---|
| 001 | 02312GNF | 480GB, SATA, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 002 | 02312GNG | 480GB, SATA, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 003 | 02312GNR | 480GB, SATA, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 004 | 02312GNS | 480GB, SATA, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 005 | 02312GTM | 480GB, SATA, 3.5″, mixed use | FusionServer V5–V6 | Look up → |
| 006 | 02312GTR | 480GB, SATA, 2.5″, mixed use | FusionServer V5–V6 | Look up → |
| 007 | 02312GUC | 480GB, SATA, 2.5″, mixed use | FusionServer V5–V6 | Look up → |
| 008 | 02312XAK | 480GB, SATA, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 009 | 02312XAL | 480GB, SATA, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 010 | 02313EYV | 480GB, SATA, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 011 | 02313EYX | 480GB, SATA, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 012 | 02550173 | 480GB, SATA, 2.5″, mixed use | FusionServer V5–V6 | Look up → |
| 013 | 02550199 | 480GB, SATA, 3.5″, mixed use | FusionServer V5–V6 | Look up → |
| 014 | 0255Y006 | 480GB, SATA, 2.5″, mixed use | FusionServer V5–V6 | Look up → |
| 015 | 0255Y007 | 480GB, SATA, 3.5″, mixed use | FusionServer V5–V6 | Look up → |
| 016 | 0255Y016 | 480GB, SATA, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 017 | 0255Y017 | 480GB, SATA, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 018 | 0255Y041 | 480GB, SATA, 2.5″, mixed use | FusionServer V5–V6 | Look up → |
| 019 | 0255Y042 | 480GB, SATA, 3.5″, mixed use | FusionServer V5–V6 | Look up → |
| 020 | 0255Y049 | 480GB, SATA, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 021 | 0255Y050 | 480GB, SATA, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 022 | 0255Y055 | 480GB, SATA, 2.5″, read intensive | FusionServer V5–V7 | Look up → |
| 023 | 0255Y056 | 480GB, SATA, 3.5″, read intensive | FusionServer V5–V7 | Look up → |
| 024 | 0255Y079 | 480GB, SATA, 3.5″, read intensive | FusionServer V6 | Look up → |
| 025 | 0255Y100 | 480GB, SATA, 2.5″, read intensive | FusionServer V6 | Look up → |
| 026 | 0255Y107 | 480GB, SATA, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 027 | 0255Y108 | 480GB, SATA, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 028 | 0255Y120 | 480GB, SATA, 3.5″, read intensive | FusionServer V7 | Look up → |
| 029 | 0255Y227 | 480GB, SATA, 2.5″, read intensive | FusionServer V6 | Look up → |
| 030 | 0255Y370 | 480GB, SATA, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 031 | 0255Y399 | 480GB, SATA, 2.5″, read intensive | FusionServer V7 | Look up → |
| 032 | 0255Y400 | 480GB, SATA, 3.5″, read intensive | FusionServer V6–V7 | Look up → |
| 033 | 0255Y407 | 480GB, SATA, 2.5″, mixed use | FusionServer V7 | Look up → |
| 034 | 0255Y408 | 480GB, SATA, 3.5″, mixed use | FusionServer V6–V7 | Look up → |
| 035 | 0255Y417 | 480GB, SATA, 2.5″, read intensive | FusionServer V7–V8 | Look up → |
| 036 | 0255Y418 | 480GB, SATA, 3.5″, read intensive | FusionServer V6–V8 | Look up → |
| 037 | 0255Y427 | 480GB, SATA, 2.5″, mixed use | FusionServer V7–V8 | Look up → |
| 038 | 0255Y428 | 480GB, SATA, 3.5″, mixed use | FusionServer V6–V8 | Look up → |
| 039 | 0255Y436 | 480GB, SATA, 2.5″, read intensive | FusionServer V7 | Look up → |
| 040 | 0255Y437 | 480GB, SATA, 3.5″, read intensive | FusionServer V7 | Look up → |
| 041 | 0255Y444 | 480GB, SATA, 2.5″, read intensive | FusionServer V7 | Look up → |
| 042 | 0255Y445 | 480GB, SATA, 3.5″, read intensive | FusionServer V6–V7 | Look up → |
| 043 | 0255Y452 | 480GB, SATA, 2.5″, read intensive | FusionServer V7 | Look up → |
| 044 | 0255Y453 | 480GB, SATA, 3.5″, read intensive | FusionServer V6–V7 | Look up → |
| 045 | 0255Y640 | 480GB, SATA, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 046 | 0255Y641 | 480GB, SATA, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 047 | 0255Y773 | 480GB, SATA, 2.5″, read intensive | FusionServer V6 | Look up → |
| 048 | 0255Y774 | 480GB, SATA, 3.5″, read intensive | FusionServer V6 | Look up → |
| 049 | 0255Y889 | 480GB, SATA, 2.5″, read intensive | FusionServer V7 | Look up → |
| 050 | 0255Y890 | 480GB, SATA, 3.5″, read intensive | FusionServer V7 | Look up → |
| 051 | 0255YABW | 480GB, SATA, 2.5″, read intensive | FusionServer V6 | Look up → |
| 052 | 0255YABX | 480GB, SATA, 3.5″, read intensive | FusionServer V6 | Look up → |
| 053 | 0255YACT | 480GB, SATA, 2.5″, mixed use | FusionServer V7 | Look up → |
| 054 | 0255YADJ | 480GB, SATA, 2.5″, read intensive | FusionServer V7 | Look up → |
| 055 | 0255YAET | 480GB, SATA, 2.5″, read intensive | FusionServer V7 | Look up → |
| 056 | 0255YAEU | 480GB, SATA, 3.5″, read intensive | FusionServer V7 | Look up → |
| 057 | 0255YAFP | 480GB, SATA, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 058 | 0255YAFQ | 480GB, SATA, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 059 | 0255YAFV | 480GB, SATA, 3.5″, mixed use | FusionServer V5–V6 | Look up → |
| 060 | 0255YAPD | 480GB, SATA, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 061 | 0255YAPE | 480GB, SATA, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 062 | 0255YAPG | 480GB, SATA, 2.5″, read intensive | FusionServer V7 | Look up → |
| 063 | 0255YAPV | 480GB, SATA, 2.5″, mixed use | FusionServer V5–V6 | Look up → |
| 064 | 0255YAPW | 480GB, SATA, 3.5″, mixed use | FusionServer V5–V6 | Look up → |
| 065 | 0255YAWN | 480GB, SATA, 3.5″ | FusionServer V7–V8 | Look up → |
| 066 | 0255YAWP | 480GB, SATA, 2.5″, read intensive | FusionServer V7–V8 | Look up → |
| 067 | 0255YAWW | 480GB, SATA, 3.5″, read intensive | FusionServer V6 | Look up → |
| 068 | 0255YAWX | 480GB, SATA, 2.5″, read intensive | FusionServer V6 | Look up → |
| 069 | 0255YAYB | 480GB, SATA, 2.5″, read intensive | FusionServer V7 | Look up → |
| 070 | 0255YAYC | 480GB, SATA, 3.5″, read intensive | FusionServer V7 | Look up → |
| 071 | 0255YBBN | 480GB, SATA, 3.5″, read intensive | FusionServer V7–V8 | Look up → |
| 072 | 0255YBHM | 480GB, SATA, 2.5″, read intensive | FusionServer V7–V8 | Look up → |
| 073 | 0255YBKH | 480GB, SATA, 3.5″, read intensive | FusionServer V6 | Look up → |
| 074 | 0255YBKJ | 480GB, SATA, 3.5″, read intensive | FusionServer V6 | Look up → |
| 075 | 0255YBQQ | 480GB, SATA, 2.5″, read intensive | FusionServer V6 | Look up → |
| 076 | 0255YBQR | 480GB, SATA, 2.5″, read intensive | FusionServer V7 | Look up → |
| 077 | 0255YCFS | 480GB, SATA, 2.5″, read intensive | FusionServer V7 | Look up → |
| 078 | 0255YCFT | 480GB, SATA, 3.5″, read intensive | FusionServer V7 | Look up → |
| 079 | 0255YCHT | 480GB, SATA, 2.5″, read intensive | FusionServer V8 | Look up → |
| 080 | 0255YCJH | 480GB, SATA, 3.5″, read intensive | FusionServer V6 | Look up → |
| 081 | 0255YCJL | 480GB, SATA, 2.5″, read intensive | FusionServer V6 | Look up → |
| 082 | 0255YCJR | 480GB, SATA, 2.5″, read intensive | FusionServer V6 | Look up → |
| 083 | 0255YCJS | 480GB, SATA, 3.5″, read intensive | FusionServer V6 | Look up → |
| 084 | 0255YDBG | 480GB, SATA, M.2 | FusionServer V7 | Look up → |
| 085 | 0255YDFV | 480GB, SATA, 3.5″ | FusionServer V7 | Look up → |
| 086 | 0255YDUH | 480GB, SATA, 2.5″, read intensive | FusionServer V7–V8 | Look up → |
| 087 | 0255YDUJ | 480GB, SATA, 3.5″, read intensive | FusionServer V7–V8 | Look up → |
| 088 | 0255YELE | 480GB, SATA, 2.5″, read intensive | FusionServer V8 | Look up → |
| 089 | 0255YEMC | 480GB, SATA, 2.5″, read intensive | FusionServer V8 | Look up → |
| 090 | 0255YENG | 480GB, SATA, 3.5″, read intensive | FusionServer V7 | Look up → |
| 091 | 0255YENU | 480GB, SATA, 2.5″, read intensive | FusionServer V7 | Look up → |
Not sure which of these fits your server? Check the xFusion compatibility center by model and ESN, or send us any part number for an exact match.
SATA SSD 960GB — 77 official part numbers (V5–V8)
| # | Part number | Specification | Compatibility | Look up |
|---|---|---|---|---|
| 001 | 02312GNH | 960GB, SATA, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 002 | 02312GNJ | 960GB, SATA, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 003 | 02312GNT | 960GB, SATA, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 004 | 02312GNU | 960GB, SATA, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 005 | 02312GTN | 960GB, SATA, 3.5″, mixed use | FusionServer V5–V6 | Look up → |
| 006 | 02312GTS | 960GB, SATA, 2.5″, mixed use | FusionServer V5–V6 | Look up → |
| 007 | 02312GUE | 960GB, SATA, 2.5″, mixed use | FusionServer V5–V6 | Look up → |
| 008 | 02312XAM | 960GB, SATA, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 009 | 02312XAN | 960GB, SATA, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 010 | 02313FAC | 960GB, SATA, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 011 | 02313FAD | 960GB, SATA, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 012 | 02550206 | 960GB, SATA, 2.5″, mixed use | FusionServer V5–V6 | Look up → |
| 013 | 02550207 | 960GB, SATA, 3.5″, mixed use | FusionServer V5–V6 | Look up → |
| 014 | 0255Y008 | 960GB, SATA, 2.5″, mixed use | FusionServer V5–V6 | Look up → |
| 015 | 0255Y009 | 960GB, SATA, 3.5″, mixed use | FusionServer V5–V6 | Look up → |
| 016 | 0255Y018 | 960GB, SATA, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 017 | 0255Y019 | 960GB, SATA, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 018 | 0255Y033 | 960GB, SATA, 3.5″, mixed use | FusionServer V5–V6 | Look up → |
| 019 | 0255Y034 | 960GB, SATA, 2.5″, mixed use | FusionServer V5–V6 | Look up → |
| 020 | 0255Y047 | 960GB, SATA, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 021 | 0255Y048 | 960GB, SATA, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 022 | 0255Y057 | 960GB, SATA, 2.5″, read intensive | FusionServer V5–V7 | Look up → |
| 023 | 0255Y058 | 960GB, SATA, 3.5″, read intensive | FusionServer V5–V7 | Look up → |
| 024 | 0255Y109 | 960GB, SATA, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 025 | 0255Y110 | 960GB, SATA, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 026 | 0255Y113 | 960GB, SATA, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 027 | 0255Y114 | 960GB, SATA, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 028 | 0255Y401 | 960GB, SATA, 2.5″, read intensive | FusionServer V7 | Look up → |
| 029 | 0255Y402 | 960GB, SATA, 3.5″, read intensive | FusionServer V6–V7 | Look up → |
| 030 | 0255Y409 | 960GB, SATA, 2.5″, mixed use | FusionServer V7 | Look up → |
| 031 | 0255Y410 | 960GB, SATA, 3.5″, mixed use | FusionServer V6–V7 | Look up → |
| 032 | 0255Y419 | 960GB, SATA, 2.5″, read intensive | FusionServer V7–V8 | Look up → |
| 033 | 0255Y420 | 960GB, SATA, 3.5″, read intensive | FusionServer V6–V8 | Look up → |
| 034 | 0255Y425 | 960GB, SATA, 2.5″, read intensive | FusionServer V7 | Look up → |
| 035 | 0255Y426 | 960GB, SATA, 3.5″, read intensive | FusionServer V7 | Look up → |
| 036 | 0255Y429 | 960GB, SATA, 2.5″, mixed use | FusionServer V7–V8 | Look up → |
| 037 | 0255Y430 | 960GB, SATA, 3.5″, mixed use | FusionServer V6–V8 | Look up → |
| 038 | 0255Y438 | 960GB, SATA, 2.5″, read intensive | FusionServer V7 | Look up → |
| 039 | 0255Y439 | 960GB, SATA, 3.5″, read intensive | FusionServer V7 | Look up → |
| 040 | 0255Y446 | 960GB, SATA, 2.5″, read intensive | FusionServer V7 | Look up → |
| 041 | 0255Y447 | 960GB, SATA, 3.5″, read intensive | FusionServer V6–V7 | Look up → |
| 042 | 0255Y454 | 960GB, SATA, 2.5″, read intensive | FusionServer V7 | Look up → |
| 043 | 0255Y455 | 960GB, SATA, 3.5″, read intensive | FusionServer V6–V7 | Look up → |
| 044 | 0255Y495 | 960GB, SATA, 2.5″, mixed use | FusionServer V5–V6 | Look up → |
| 045 | 0255Y496 | 960GB, SATA, 3.5″, mixed use | FusionServer V5–V6 | Look up → |
| 046 | 0255Y642 | 960GB, SATA, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 047 | 0255Y643 | 960GB, SATA, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 048 | 0255Y775 | 960GB, SATA, 2.5″, read intensive | FusionServer V6 | Look up → |
| 049 | 0255Y776 | 960GB, SATA, 3.5″, read intensive | FusionServer V6 | Look up → |
| 050 | 0255Y891 | 960GB, SATA, 2.5″, read intensive | FusionServer V7 | Look up → |
| 051 | 0255Y892 | 960GB, SATA, 3.5″, read intensive | FusionServer V7 | Look up → |
| 052 | 0255YACY | 960GB, SATA, 2.5″, mixed use | FusionServer V7 | Look up → |
| 053 | 0255YADL | 960GB, SATA, 2.5″, read intensive | FusionServer V7 | Look up → |
| 054 | 0255YAGD | 960GB, SATA, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 055 | 0255YAGE | 960GB, SATA, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 056 | 0255YAGH | 960GB, SATA, 3.5″, mixed use | FusionServer V5–V6 | Look up → |
| 057 | 0255YAGJ | 960GB, SATA, 2.5″, mixed use | FusionServer V5–V6 | Look up → |
| 058 | 0255YAKD | 960GB, SATA, 2.5″, read intensive | FusionServer V7 | Look up → |
| 059 | 0255YAKE | 960GB, SATA, 3.5″, read intensive | FusionServer V7 | Look up → |
| 060 | 0255YAPH | 960GB, SATA, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 061 | 0255YAPJ | 960GB, SATA, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 062 | 0255YAWQ | 960GB, SATA, 2.5″, read intensive | FusionServer V7 | Look up → |
| 063 | 0255YAWR | 960GB, SATA, 3.5″ | FusionServer V7 | Look up → |
| 064 | 0255YAWY | 960GB, SATA, 2.5″, read intensive | FusionServer V6 | Look up → |
| 065 | 0255YAXA | 960GB, SATA, 3.5″, read intensive | FusionServer V6 | Look up → |
| 066 | 0255YAYD | 960GB, SATA, 2.5″, read intensive | FusionServer V7 | Look up → |
| 067 | 0255YAYE | 960GB, SATA, 3.5″, read intensive | FusionServer V6–V7 | Look up → |
| 068 | 0255YCGK | 960GB, SATA, 2.5″, read intensive | FusionServer V7 | Look up → |
| 069 | 0255YCGL | 960GB, SATA, 3.5″, read intensive | FusionServer V7 | Look up → |
| 070 | 0255YCJY | 960GB, SATA, 2.5″, read intensive | FusionServer V6 | Look up → |
| 071 | 0255YCKA | 960GB, SATA, 3.5″, read intensive | FusionServer V6 | Look up → |
| 072 | 0255YDKU | 960GB, SATA, 3.5″, read intensive | FusionServer V6 | Look up → |
| 073 | 0255YDNH | 960GB, SATA, 2.5″, read intensive | FusionServer V7 | Look up → |
| 074 | 0255YDNJ | 960GB, SATA, 3.5″ | FusionServer V7 | Look up → |
| 075 | 0255YDUM | 960GB, SATA, 2.5″, read intensive | FusionServer V7–V8 | Look up → |
| 076 | 0255YDUN | 960GB, SATA, 3.5″, read intensive | FusionServer V7–V8 | Look up → |
| 077 | 0255YELG | 960GB, SATA, 2.5″, read intensive | FusionServer V8 | Look up → |
Not sure which of these fits your server? Check the xFusion compatibility center by model and ESN, or send us any part number for an exact match.
SATA SSD 1.92TB — 65 official part numbers (V5–V8)
| # | Part number | Specification | Compatibility | Look up |
|---|---|---|---|---|
| 001 | 02312GNK | 1.92TB, SATA, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 002 | 02312GNL | 1.92TB, SATA, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 003 | 02312GNW | 1.92TB, SATA, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 004 | 02312GNX | 1.92TB, SATA, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 005 | 02312GTP | 1.92TB, SATA, 3.5″, mixed use | FusionServer V5–V6 | Look up → |
| 006 | 02312GTT | 1.92TB, SATA, 2.5″, mixed use | FusionServer V5–V6 | Look up → |
| 007 | 02312GUF | 1.92TB, SATA, 2.5″, mixed use | FusionServer V5–V6 | Look up → |
| 008 | 02313DHT | 1.92TB, SATA, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 009 | 02313DHU | 1.92TB, SATA, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 010 | 02313FAE | 1.92TB, SATA, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 011 | 02313FAF | 1.92TB, SATA, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 012 | 02550210 | 1.92TB, SATA, 2.5″, mixed use | FusionServer V5–V6 | Look up → |
| 013 | 02550211 | 1.92TB, SATA, 3.5″, mixed use | FusionServer V5–V6 | Look up → |
| 014 | 0255Y010 | 1.92TB, SATA, 2.5″, mixed use | FusionServer V5–V6 | Look up → |
| 015 | 0255Y011 | 1.92TB, SATA, 3.5″, mixed use | FusionServer V5–V6 | Look up → |
| 016 | 0255Y020 | 1.92TB, SATA, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 017 | 0255Y021 | 1.92TB, SATA, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 018 | 0255Y035 | 1.92TB, SATA, 2.5″, mixed use | FusionServer V5–V6 | Look up → |
| 019 | 0255Y036 | 1.92TB, SATA, 3.5″, mixed use | FusionServer V5–V6 | Look up → |
| 020 | 0255Y045 | 1.92TB, SATA, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 021 | 0255Y046 | 1.92TB, SATA, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 022 | 0255Y059 | 1.92TB, SATA, 2.5″, read intensive | FusionServer V5–V7 | Look up → |
| 023 | 0255Y060 | 1.92TB, SATA, 3.5″, read intensive | FusionServer V5–V7 | Look up → |
| 024 | 0255Y111 | 1.92TB, SATA, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 025 | 0255Y112 | 1.92TB, SATA, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 026 | 0255Y347 | 1.92TB, SATA, 3.5″, mixed use | FusionServer V6–V8 | Look up → |
| 027 | 0255Y403 | 1.92TB, SATA, 2.5″, read intensive | FusionServer V7 | Look up → |
| 028 | 0255Y404 | 1.92TB, SATA, 3.5″, read intensive | FusionServer V6–V7 | Look up → |
| 029 | 0255Y411 | 1.92TB, SATA, 2.5″, mixed use | FusionServer V7 | Look up → |
| 030 | 0255Y412 | 1.92TB, SATA, 3.5″, mixed use | FusionServer V6–V7 | Look up → |
| 031 | 0255Y421 | 1.92TB, SATA, 2.5″, read intensive | FusionServer V7–V8 | Look up → |
| 032 | 0255Y422 | 1.92TB, SATA, 3.5″, read intensive | FusionServer V6–V8 | Look up → |
| 033 | 0255Y431 | 1.92TB, SATA, 2.5″, mixed use | FusionServer V7–V8 | Look up → |
| 034 | 0255Y440 | 1.92TB, SATA, 2.5″, read intensive | FusionServer V7 | Look up → |
| 035 | 0255Y441 | 1.92TB, SATA, 3.5″, read intensive | FusionServer V7 | Look up → |
| 036 | 0255Y448 | 1.92TB, SATA, 2.5″, read intensive | FusionServer V7 | Look up → |
| 037 | 0255Y449 | 1.92TB, SATA, 3.5″, read intensive | FusionServer V6–V7 | Look up → |
| 038 | 0255Y456 | 1.92TB, SATA, 2.5″, read intensive | FusionServer V7 | Look up → |
| 039 | 0255Y457 | 1.92TB, SATA, 3.5″, read intensive | FusionServer V6–V7 | Look up → |
| 040 | 0255Y644 | 1.92TB, SATA, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 041 | 0255Y645 | 1.92TB, SATA, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 042 | 0255Y893 | 1.92TB, SATA, 2.5″, read intensive | FusionServer V7 | Look up → |
| 043 | 0255YACW | 1.92TB, SATA, 2.5″, mixed use | FusionServer V7 | Look up → |
| 044 | 0255YADN | 1.92TB, SATA, 2.5″, read intensive | FusionServer V7 | Look up → |
| 045 | 0255YAGX | 1.92TB, SATA, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 046 | 0255YAGY | 1.92TB, SATA, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 047 | 0255YAHA | 1.92TB, SATA, 2.5″, read intensive | FusionServer V7 | Look up → |
| 048 | 0255YAHD | 1.92TB, SATA, 3.5″, mixed use | FusionServer V5–V6 | Look up → |
| 049 | 0255YAKG | 1.92TB, SATA, 2.5″, read intensive | FusionServer V7 | Look up → |
| 050 | 0255YAKH | 1.92TB, SATA, 3.5″, read intensive | FusionServer V7 | Look up → |
| 051 | 0255YAPM | 1.92TB, SATA, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 052 | 0255YAPN | 1.92TB, SATA, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 053 | 0255YAQF | 1.92TB, SATA, 3.5″, mixed use | FusionServer V5–V6 | Look up → |
| 054 | 0255YAUG | 1.92TB, SATA, 2.5″, read intensive | FusionServer V6 | Look up → |
| 055 | 0255YAWS | 1.92TB, SATA, 2.5″, read intensive | FusionServer V7 | Look up → |
| 056 | 0255YAWT | 1.92TB, SATA, 3.5″ | FusionServer V7 | Look up → |
| 057 | 0255YAXB | 1.92TB, SATA, 2.5″, read intensive | FusionServer V6 | Look up → |
| 058 | 0255YAXC | 1.92TB, SATA, 3.5″, read intensive | FusionServer V6 | Look up → |
| 059 | 0255YCGV | 1.92TB, SATA, 2.5″, read intensive | FusionServer V7 | Look up → |
| 060 | 0255YCGW | 1.92TB, SATA, 3.5″, read intensive | FusionServer V7 | Look up → |
| 061 | 0255YCMN | 1.92TB, SATA, 3.5″, read intensive | FusionServer V6 | Look up → |
| 062 | 0255YCMP | 1.92TB, SATA, 3.5″, read intensive | FusionServer V7 | Look up → |
| 063 | 0255YCMQ | 1.92TB, SATA, 2.5″, read intensive | FusionServer V7 | Look up → |
| 064 | 0255YDUR | 1.92TB, SATA, 2.5″, read intensive | FusionServer V7–V8 | Look up → |
| 065 | 0255YDUS | 1.92TB, SATA, 3.5″, read intensive | FusionServer V7–V8 | Look up → |
Not sure which of these fits your server? Check the xFusion compatibility center by model and ESN, or send us any part number for an exact match.
SATA SSD 2TB — 1 official part numbers (V5–V6)
| # | Part number | Specification | Compatibility | Look up |
|---|---|---|---|---|
| 001 | 02311AYT | 2TB, SATA, 3.5″, 7200 RPM | FusionServer V5–V6 | Look up → |
Not sure which of these fits your server? Check the xFusion compatibility center by model and ESN, or send us any part number for an exact match.
SATA SSD 3.84TB — 42 official part numbers (V5–V8)
| # | Part number | Specification | Compatibility | Look up |
|---|---|---|---|---|
| 001 | 02312GNM | 3.84TB, SATA, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 002 | 02312GNN | 3.84TB, SATA, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 003 | 02312GNY | 3.84TB, SATA, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 004 | 02312GPA | 3.84TB, SATA, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 005 | 02312KGG | 3.84TB, SATA, 2.5″, mixed use | FusionServer V5–V6 | Look up → |
| 006 | 02312KGK | 3.84TB, SATA, 3.5″, mixed use | FusionServer V5–V6 | Look up → |
| 007 | 02313FAG | 3.84TB, SATA, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 008 | 02313FAJ | 3.84TB, SATA, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 009 | 0255Y012 | 3.84TB, SATA, 2.5″, mixed use | FusionServer V5–V6 | Look up → |
| 010 | 0255Y013 | 3.84TB, SATA, 3.5″, mixed use | FusionServer V5–V6 | Look up → |
| 011 | 0255Y022 | 3.84TB, SATA, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 012 | 0255Y023 | 3.84TB, SATA, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 013 | 0255Y037 | 3.84TB, SATA, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 014 | 0255Y038 | 3.84TB, SATA, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 015 | 0255Y043 | 3.84TB, SATA, 2.5″, mixed use | FusionServer V5–V6 | Look up → |
| 016 | 0255Y044 | 3.84TB, SATA, 3.5″, mixed use | FusionServer V5–V6 | Look up → |
| 017 | 0255Y405 | 3.84TB, SATA, 2.5″, read intensive | FusionServer V7 | Look up → |
| 018 | 0255Y406 | 3.84TB, SATA, 3.5″, read intensive | FusionServer V6–V7 | Look up → |
| 019 | 0255Y413 | 3.84TB, SATA, 2.5″, mixed use | FusionServer V7 | Look up → |
| 020 | 0255Y414 | 3.84TB, SATA, 3.5″, mixed use | FusionServer V6–V7 | Look up → |
| 021 | 0255Y423 | 3.84TB, SATA, 2.5″, read intensive | FusionServer V7–V8 | Look up → |
| 022 | 0255Y424 | 3.84TB, SATA, 3.5″, read intensive | FusionServer V6–V8 | Look up → |
| 023 | 0255Y432 | 3.84TB, SATA, 2.5″, mixed use | FusionServer V7–V8 | Look up → |
| 024 | 0255Y433 | 3.84TB, SATA, 3.5″, mixed use | FusionServer V6–V8 | Look up → |
| 025 | 0255YADB | 3.84TB, SATA, 2.5″, mixed use | FusionServer V7 | Look up → |
| 026 | 0255YADQ | 3.84TB, SATA, 2.5″, read intensive | FusionServer V7 | Look up → |
| 027 | 0255YAHG | 3.84TB, SATA, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 028 | 0255YAHH | 3.84TB, SATA, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 029 | 0255YAHL | 3.84TB, SATA, 2.5″, mixed use | FusionServer V5–V6 | Look up → |
| 030 | 0255YAHM | 3.84TB, SATA, 3.5″, mixed use | FusionServer V5–V6 | Look up → |
| 031 | 0255YAHP | 3.84TB, SATA, 3.5″, mixed use | FusionServer V7 | Look up → |
| 032 | 0255YAPR | 3.84TB, SATA, 2.5″, read intensive | FusionServer V5–V6 | Look up → |
| 033 | 0255YAPS | 3.84TB, SATA, 3.5″, read intensive | FusionServer V5–V6 | Look up → |
| 034 | 0255YAQL | 3.84TB, SATA, 2.5″, mixed use | FusionServer V7 | Look up → |
| 035 | 0255YAWU | 3.84TB, SATA, 2.5″, read intensive | FusionServer V7 | Look up → |
| 036 | 0255YAWV | 3.84TB, SATA, 3.5″ | FusionServer V7 | Look up → |
| 037 | 0255YAXD | 3.84TB, SATA, 2.5″, read intensive | FusionServer V6 | Look up → |
| 038 | 0255YAXE | 3.84TB, SATA, 3.5″, read intensive | FusionServer V6 | Look up → |
| 039 | 0255YCMT | 3.84TB, SATA, 2.5″, read intensive | FusionServer V7 | Look up → |
| 040 | 0255YCMU | 3.84TB, SATA, 3.5″, read intensive | FusionServer V7 | Look up → |
| 041 | 0255YDXA | 3.84TB, SATA, 2.5″, read intensive | FusionServer V7–V8 | Look up → |
| 042 | 0255YDXB | 3.84TB, SATA, 3.5″, read intensive | FusionServer V7–V8 | Look up → |
Not sure which of these fits your server? Check the xFusion compatibility center by model and ESN, or send us any part number for an exact match.
SATA SSD 4TB — 11 official part numbers (V5–V8)
| # | Part number | Specification | Compatibility | Look up |
|---|---|---|---|---|
| 001 | 02311AYV | 4TB, SATA, 3.5″ | FusionServer V5–V6 | Look up → |
| 002 | 02540041 | 4TB, SATA, 3.5″ | FusionServer V6 | Look up → |
| 003 | 0254Y065 | 4TB, SATA, 3.5″ | FusionServer V6–V7 | Look up → |
| 004 | 0254Y083 | 4TB, SATA, 3.5″, 7200 RPM | FusionServer V6 | Look up → |
| 005 | 0254Y099 | 4TB, SATA, 3.5″, 7200 RPM | FusionServer V6 | Look up → |
| 006 | 0254Y238 | 4TB, SATA, 3.5″, 7200 RPM | FusionServer V8 | Look up → |
| 007 | 0254Y239 | 4TB, SATA, 3.5″, 7200 RPM | FusionServer V7 | Look up → |
| 008 | 0254Y302 | 4TB, SATA, 3.5″ | FusionServer V6 | Look up → |
| 009 | 0254Y375 | 4TB, SATA, 3.5″, 7200 RPM | FusionServer V6 | Look up → |
| 010 | 0254Y696 | 4TB, SATA, 3.5″ | FusionServer V6–V7 | Look up → |
| 011 | 0254Y697 | 4TB, SATA, 3.5″ | FusionServer V6–V7 | Look up → |
Not sure which of these fits your server? Check the xFusion compatibility center by model and ESN, or send us any part number for an exact match.
SATA SSD 6TB — 3 official part numbers (V5–V7)
| # | Part number | Specification | Compatibility | Look up |
|---|---|---|---|---|
| 001 | 02311DYQ | 6TB, SATA, 3.5″, 7200 RPM | FusionServer V5–V6 | Look up → |
| 002 | 02540042 | 6TB, SATA, 3.5″ | FusionServer V6 | Look up → |
| 003 | 0254Y066 | 6TB, SATA, 3.5″ | FusionServer V6–V7 | Look up → |
Not sure which of these fits your server? Check the xFusion compatibility center by model and ESN, or send us any part number for an exact match.
SATA SSD 7.68TB — 4 official part numbers (V7–V8)
| # | Part number | Specification | Compatibility | Look up |
|---|---|---|---|---|
| 001 | 0255YARM | 7.68TB, SATA, 2.5″, read intensive | FusionServer V8 | Look up → |
| 002 | 0255YCPT | 7.68TB, SATA, 3.5″, read intensive | FusionServer V8 | Look up → |
| 003 | 0255YDUW | 7.68TB, SATA, 2.5″, read intensive | FusionServer V7 | Look up → |
| 004 | 0255YDUX | 7.68TB, SATA, 3.5″, read intensive | FusionServer V7 | Look up → |
Not sure which of these fits your server? Check the xFusion compatibility center by model and ESN, or send us any part number for an exact match.
SATA SSD 8TB — 20 official part numbers (V5–V8)
| # | Part number | Specification | Compatibility | Look up |
|---|---|---|---|---|
| 001 | 02311JRE | 8TB, SATA, 3.5″, 7200 RPM | FusionServer V5–V6 | Look up → |
| 002 | 02540043 | 8TB, SATA, 3.5″ | FusionServer V6 | Look up → |
| 003 | 0254Y046 | 8TB, SATA, 3.5″, 7200 RPM | FusionServer V6 | Look up → |
| 004 | 0254Y067 | 8TB, SATA, 3.5″ | FusionServer V6–V8 | Look up → |
| 005 | 0254Y076 | 8TB, SATA, 3.5″, 7200 RPM | FusionServer V5–V6 | Look up → |
| 006 | 0254Y207 | 8TB, SATA, 3.5″ | FusionServer V6 | Look up → |
| 007 | 0254Y304 | 8TB, SATA, 3.5″ | FusionServer V6 | Look up → |
| 008 | 0254Y305 | 8TB, SATA, 3.5″ | FusionServer V7 | Look up → |
| 009 | 0254Y351 | 8TB, SATA, 3.5″ | FusionServer V7 | Look up → |
| 010 | 0254Y353 | 8TB, SATA, 3.5″, 7200 RPM | FusionServer V6 | Look up → |
| 011 | 0254Y379 | 8TB, SATA, 3.5″, 7200 RPM | FusionServer V6 | Look up → |
| 012 | 0254Y380 | 8TB, SATA, 3.5″, 7200 RPM | FusionServer V6 | Look up → |
| 013 | 0254Y381 | 8TB, SATA, 3.5″, 7200 RPM | FusionServer V6 | Look up → |
| 014 | 0254Y470 | 8TB, SATA, 3.5″ | FusionServer V6–V8 | Look up → |
| 015 | 0254Y476 | 8TB, SATA, 3.5″ | FusionServer V7 | Look up → |
| 016 | 0254Y481 | 8TB, SATA, 3.5″ | FusionServer V7 | Look up → |
| 017 | 0254Y496 | 8TB, SATA, 3.5″ | FusionServer V6–V7 | Look up → |
| 018 | 0254Y603 | 8TB, SATA, 3.5″, 7200 RPM | FusionServer V7 | Look up → |
| 019 | 0254Y851 | 8TB, SATA, 3.5″ | FusionServer V8 | Look up → |
| 020 | 0254Y852 | 8TB, SATA, 3.5″ | FusionServer V7–V8 | Look up → |
Not sure which of these fits your server? Check the xFusion compatibility center by model and ESN, or send us any part number for an exact match.
SATA SSD 10TB — 4 official part numbers (V5–V7)
| # | Part number | Specification | Compatibility | Look up |
|---|---|---|---|---|
| 001 | 02311SXE | 10TB, SATA, 3.5″ | FusionServer V5–V6 | Look up → |
| 002 | 02540044 | 10TB, SATA, 3.5″ | FusionServer V6 | Look up → |
| 003 | 0254Y068 | 10TB, SATA, 3.5″ | FusionServer V6–V7 | Look up → |
| 004 | 0254Y306 | 10TB, SATA, 3.5″ | FusionServer V6 | Look up → |
Not sure which of these fits your server? Check the xFusion compatibility center by model and ESN, or send us any part number for an exact match.
SATA SSD 12TB — 9 official part numbers (V5–V7)
| # | Part number | Specification | Compatibility | Look up |
|---|---|---|---|---|
| 001 | 02312DEK | 12TB, SATA, 3.5″ | FusionServer V5–V6 | Look up → |
| 002 | 0254Y069 | 12TB, SATA, 3.5″ | FusionServer V6–V7 | Look up → |
| 003 | 0254Y089 | 12TB, SATA, 3.5″, 7200 RPM | FusionServer V6 | Look up → |
| 004 | 0254Y206 | 12TB, SATA, 3.5″ | FusionServer V6 | Look up → |
| 005 | 0254Y257 | 12TB, SATA, 3.5″, 7200 RPM | FusionServer V7 | Look up → |
| 006 | 0254Y310 | 12TB, SATA, 3.5″, 7200 RPM | FusionServer V6 | Look up → |
| 007 | 0254Y398 | 12TB, SATA, 3.5″, 7200 RPM | FusionServer V6–V7 | Look up → |
| 008 | 0254Y399 | 12TB, SATA, 3.5″, 7200 RPM | FusionServer V6–V7 | Look up → |
| 009 | 0254Y425 | 12TB, SATA, 3.5″, 7200 RPM | FusionServer V7 | Look up → |
Not sure which of these fits your server? Check the xFusion compatibility center by model and ESN, or send us any part number for an exact match.
SATA SSD 14TB — 4 official part numbers (V5–V7)
| # | Part number | Specification | Compatibility | Look up |
|---|---|---|---|---|
| 001 | 02312HPC | 14TB, SATA, 3.5″ | FusionServer V5–V6 | Look up → |
| 002 | 02312HPE | 14TB, SATA, 3.5″ | FusionServer V5–V6 | Look up → |
| 003 | 02540046 | 14TB, SATA, 3.5″ | FusionServer V6 | Look up → |
| 004 | 0254Y070 | 14TB, SATA, 3.5″ | FusionServer V6–V7 | Look up → |
Not sure which of these fits your server? Check the xFusion compatibility center by model and ESN, or send us any part number for an exact match.
SATA SSD 16TB — 23 official part numbers (V5–V8)
| # | Part number | Specification | Compatibility | Look up |
|---|---|---|---|---|
| 001 | 02312PAN | 16TB, SATA, 3.5″, 7200 RPM | FusionServer V5–V6 | Look up → |
| 002 | 02540047 | 16TB, SATA, 3.5″ | FusionServer V6 | Look up → |
| 003 | 0254Y042 | 16TB, SATA, 3.5″ | FusionServer V6 | Look up → |
| 004 | 0254Y047 | 16TB, SATA, 3.5″, 7200 RPM | FusionServer V6 | Look up → |
| 005 | 0254Y071 | 16TB, SATA, 3.5″ | FusionServer V6–V8 | Look up → |
| 006 | 0254Y101 | 16TB, SATA, 3.5″, 7200 RPM | FusionServer V6 | Look up → |
| 007 | 0254Y113 | 16TB, SATA, 3.5″, 7200 RPM | FusionServer V6 | Look up → |
| 008 | 0254Y219 | 16TB, SATA, 3.5″ | FusionServer V7 | Look up → |
| 009 | 0254Y221 | 16TB, SATA, 3.5″ | FusionServer V7 | Look up → |
| 010 | 0254Y311 | 16TB, SATA, 3.5″ | FusionServer V6 | Look up → |
| 011 | 0254Y408 | 16TB, SATA, 3.5″, 7200 RPM | FusionServer V6 | Look up → |
| 012 | 0254Y414 | 16TB, SATA, 3.5″, 7200 RPM | FusionServer V6 | Look up → |
| 013 | 0254Y423 | 16TB, SATA, 3.5″, 7200 RPM | FusionServer V7 | Look up → |
| 014 | 0254Y443 | 16TB, SATA, 3.5″ | FusionServer V6–V8 | Look up → |
| 015 | 0254Y445 | 16TB, SATA, 3.5″ | FusionServer V6–V7 | Look up → |
| 016 | 0254Y482 | 16TB, SATA, 3.5″ | FusionServer V7 | Look up → |
| 017 | 0254Y483 | 16TB, SATA, 3.5″ | FusionServer V7 | Look up → |
| 018 | 0254Y484 | 16TB, SATA, 3.5″ | FusionServer V7 | Look up → |
| 019 | 0254Y497 | 16TB, SATA, 3.5″ | FusionServer V6–V8 | Look up → |
| 020 | 0254Y692 | 16TB, SATA, 3.5″, 7200 RPM | FusionServer V6 | Look up → |
| 021 | 0254Y693 | 16TB, SATA, 3.5″ | FusionServer V6–V8 | Look up → |
| 022 | 0254Y848 | 16TB, SATA, 3.5″ | FusionServer V8 | Look up → |
| 023 | 0254Y849 | 16TB, SATA, 3.5″ | FusionServer V8 | Look up → |
Not sure which of these fits your server? Check the xFusion compatibility center by model and ESN, or send us any part number for an exact match.
SATA SSD 18TB — 8 official part numbers (V5–V7)
| # | Part number | Specification | Compatibility | Look up |
|---|---|---|---|---|
| 001 | 02540048 | 18TB, SATA, 3.5″ | FusionServer V5–V6 | Look up → |
| 002 | 0254Y013 | 18TB, SATA, 3.5″, 7200 RPM | FusionServer V6 | Look up → |
| 003 | 0254Y020 | 18TB, SATA, 3.5″, 7200 RPM | FusionServer V6 | Look up → |
| 004 | 0254Y044 | 18TB, SATA, 3.5″, 7200 RPM | FusionServer V6 | Look up → |
| 005 | 0254Y072 | 18TB, SATA, 3.5″ | FusionServer V6–V7 | Look up → |
| 006 | 0254Y172 | 18TB, SATA, 3.5″ | FusionServer V6 | Look up → |
| 007 | 0254Y614 | 18TB, SATA, 3.5″, 7200 RPM | FusionServer V6 | Look up → |
| 008 | 0254Y694 | 18TB, SATA, 3.5″ | FusionServer V6 | Look up → |
Not sure which of these fits your server? Check the xFusion compatibility center by model and ESN, or send us any part number for an exact match.
SATA SSD 20TB — 28 official part numbers (V6–V8)
| # | Part number | Specification | Compatibility | Look up |
|---|---|---|---|---|
| 001 | 0254Y075 | 20TB, SATA, 3.5″, 7200 RPM | FusionServer V6 | Look up → |
| 002 | 0254Y081 | 20TB, SATA, 3.5″, 7200 RPM | FusionServer V6 | Look up → |
| 003 | 0254Y091 | 20TB, SATA, 3.5″, 7200 RPM | FusionServer V6 | Look up → |
| 004 | 0254Y096 | 20TB, SATA, 3.5″ | FusionServer V6–V8 | Look up → |
| 005 | 0254Y105 | 20TB, SATA, 3.5″, 7200 RPM | FusionServer V6 | Look up → |
| 006 | 0254Y109 | 20TB, SATA, 3.5″, 7200 RPM | FusionServer V6 | Look up → |
| 007 | 0254Y213 | 20TB, SATA, 3.5″, 7200 RPM | FusionServer V6 | Look up → |
| 008 | 0254Y222 | 20TB, SATA, 3.5″ | FusionServer V7 | Look up → |
| 009 | 0254Y252 | 20TB, SATA, 3.5″, 7200 RPM | FusionServer V6 | Look up → |
| 010 | 0254Y253 | 20TB, SATA, 3.5″, 7200 RPM | FusionServer V6 | Look up → |
| 011 | 0254Y314 | 20TB, SATA, 3.5″, 7200 RPM | FusionServer V6 | Look up → |
| 012 | 0254Y424 | 20TB, SATA, 3.5″, 7200 RPM | FusionServer V7 | Look up → |
| 013 | 0254Y441 | 20TB, SATA, 3.5″, 7200 RPM | FusionServer V6 | Look up → |
| 014 | 0254Y442 | 20TB, SATA, 3.5″ | FusionServer V6–V7 | Look up → |
| 015 | 0254Y462 | 20TB, SATA, 3.5″, 7200 RPM | FusionServer V7 | Look up → |
| 016 | 0254Y471 | 20TB, SATA, 3.5″, 7200 RPM | FusionServer V6 | Look up → |
| 017 | 0254Y485 | 20TB, SATA, 3.5″ | FusionServer V7 | Look up → |
| 018 | 0254Y486 | 20TB, SATA, 3.5″ | FusionServer V7 | Look up → |
| 019 | 0254Y487 | 20TB, SATA, 3.5″ | FusionServer V7 | Look up → |
| 020 | 0254Y498 | 20TB, SATA, 3.5″ | FusionServer V6–V8 | Look up → |
| 021 | 0254Y499 | 20TB, SATA, 3.5″ | FusionServer V6–V7 | Look up → |
| 022 | 0254Y534 | 20TB, SATA, 3.5″, 7200 RPM | FusionServer V7 | Look up → |
| 023 | 0254Y542 | 20TB, SATA, 3.5″, 7200 RPM | FusionServer V6 | Look up → |
| 024 | 0254Y632 | 20TB, SATA, 3.5″, 7200 RPM | FusionServer V6 | Look up → |
| 025 | 0254Y665 | 20TB, SATA, 3.5″, 7200 RPM | FusionServer V7 | Look up → |
| 026 | 0254Y691 | 20TB, SATA, 3.5″ | FusionServer V6–V8 | Look up → |
| 027 | 0254Y809 | 20TB, SATA, 3.5″, 7200 RPM | FusionServer V7 | Look up → |
| 028 | 0254Y850 | 20TB, SATA, 3.5″ | FusionServer V7–V8 | Look up → |
Not sure which of these fits your server? Check the xFusion compatibility center by model and ESN, or send us any part number for an exact match.
SATA SSD 22TB — 2 official part numbers (V6–V7)
| # | Part number | Specification | Compatibility | Look up |
|---|---|---|---|---|
| 001 | 0254Y080 | 22TB, SATA, 3.5″, 7200 RPM | FusionServer V6 | Look up → |
| 002 | 0254Y348 | 22TB, SATA, 3.5″, 7200 RPM | FusionServer V7 | Look up → |
Not sure which of these fits your server? Check the xFusion compatibility center by model and ESN, or send us any part number for an exact match.
SATA SSD 24TB — 18 official part numbers (V6–V8)
| # | Part number | Specification | Compatibility | Look up |
|---|---|---|---|---|
| 001 | 0254Y364 | 24TB, SATA, 3.5″ | FusionServer V7–V8 | Look up → |
| 002 | 0254Y374 | 24TB, SATA, 3.5″, 7200 RPM | FusionServer V7 | Look up → |
| 003 | 0254Y412 | 24TB, SATA, 3.5″, 7200 RPM | FusionServer V7 | Look up → |
| 004 | 0254Y413 | 24TB, SATA, 3.5″ | FusionServer V6 | Look up → |
| 005 | 0254Y426 | 24TB, SATA, 3.5″, 7200 RPM | FusionServer V7 | Look up → |
| 006 | 0254Y428 | 24TB, SATA, 3.5″, 7200 RPM | FusionServer V7 | Look up → |
| 007 | 0254Y525 | 24TB, SATA, 3.5″ | FusionServer V6 | Look up → |
| 008 | 0254Y526 | 24TB, SATA, 3.5″ | FusionServer V7 | Look up → |
| 009 | 0254Y548 | 24TB, SATA, 3.5″ | FusionServer V6 | Look up → |
| 010 | 0254Y678 | 24TB, SATA, 3.5″ | FusionServer V6 | Look up → |
| 011 | 0254Y798 | 24TB, SATA, 3.5″, 7200 RPM | FusionServer V8 | Look up → |
| 012 | 0254Y804 | 24TB, SATA, 3.5″ | FusionServer V7–V8 | Look up → |
| 013 | 0254Y810 | 24TB, SATA, 3.5″ | FusionServer V7 | Look up → |
| 014 | 0254Y813 | 24TB, SATA, 3.5″, 7200 RPM | FusionServer V7 | Look up → |
| 015 | 0254Y817 | 24TB, SATA, 3.5″ | FusionServer V8 | Look up → |
| 016 | 0254Y841 | 24TB, SATA, 3.5″, 7200 RPM | FusionServer V7 | Look up → |
| 017 | 0254Y859 | 24TB, SATA, 3.5″ | FusionServer V7 | Look up → |
| 018 | 0254Y915 | 24TB, SATA, 3.5″ | FusionServer V8 | Look up → |
Not sure which of these fits your server? Check the xFusion compatibility center by model and ESN, or send us any part number for an exact match.
SATA SSD 26TB — 1 official part numbers (V7–V7)
| # | Part number | Specification | Compatibility | Look up |
|---|---|---|---|---|
| 001 | 0254Y684 | 26TB, SATA, 3.5″, 7200 RPM | FusionServer V7 | Look up → |
Not sure which of these fits your server? Check the xFusion compatibility center by model and ESN, or send us any part number for an exact match.
SATA SSD 30TB — 4 official part numbers (V7–V8)
| # | Part number | Specification | Compatibility | Look up |
|---|---|---|---|---|
| 001 | 0254Y683 | 30TB, SATA, 3.5″, 7200 RPM | FusionServer V7 | Look up → |
| 002 | 0254Y795 | 30TB, SATA, 3.5″ | FusionServer V7–V8 | Look up → |
| 003 | 0254Y796 | 30TB, SATA, 3.5″, 7200 RPM | FusionServer V7 | Look up → |
| 004 | 0254Y842 | 30TB, SATA, 3.5″, 7200 RPM | FusionServer V7 | Look up → |
Not sure which of these fits your server? Check the xFusion compatibility center by model and ESN, or send us any part number for an exact match.
SATA SSD 32TB — 1 official part numbers (V7–V7)
| # | Part number | Specification | Compatibility | Look up |
|---|---|---|---|---|
| 001 | 0254Y909 | 32TB, SATA, 3.5″, 7200 RPM | FusionServer V7 | Look up → |
Not sure which of these fits your server? Check the xFusion compatibility center by model and ESN, or send us any part number for an exact match.
Frequently asked questions
Are these drives supplied with a xFusion carrier?
They are the official xFusion spare P/N for the listed chassis; the carrier/tray matching your cage is confirmed before quoting.
Can I replace a SAS drive with SATA or NVMe?
SATA fits most SAS backplanes, but NVMe needs an NVMe-capable backplane and controller. Send your model and we confirm.
Why do several P/N share one capacity?
xFusion uses multiple drive vendors and order codes across generations. We list representative codes and match yours exactly.
What is the largest drive available?
The current catalog includes 60 TB PCIe 5.0 NVMe and ~30 TB nearline SATA/NL-SAS drives for V8 platforms.
Request a quotation for this part
Share your FusionServer model or ESN and the configuration you need. We verify compatibility, then provide a fixed USD price and shipping options.
WeChat
Scan the QR Code with wechat
