xFusion FusionServer Servers
the flagship 2U 2288 V8 and 1U 1288 V8 on Intel Xeon 6, and the 2U single-socket
2158H V8 and dual-socket 2258H V8 on AMD EPYC 9004/9005, together with the proven V7, V6 and V5
FusionServer generations. Every unit is configured to order, tested and covered by a 3-year warranty; batch orders are
matched and palletized for export.
About xFusion FusionServer
xFusion is the enterprise-server brand spun out of Huawei’s x86 server business, carrying forward the FusionServer
lineage. FusionServer rack systems are widely deployed in telecom, finance, internet and government data centers, and
are fully compatible with mainstream virtualization, cloud and Linux stacks. The range spans 1U and 2U general-purpose
servers on Intel Xeon and AMD EPYC, with shared management (iBMC and FusionDirector), hot-snap cooling and redundant
power across the family.
xFusion FusionServer Models Available
Current generation — xFusion V8
FusionServer 2288 V8 — 2U Dual Xeon 6
The flagship mainstream 2U on Intel Xeon 6 Granite Rapids: up to 128 cores per node, 12 TB of DDR5-6400 memory and PCIe 5.0 I/O for virtualization, in-memory databases and cloud.
- 2U, 2 × Intel Xeon 6 (Granite Rapids, up to 350 W)
- 32 × DDR5 up to 6400 MT/s, maximum 12 TB
- Up to 24 × 2.5-inch drives, NVMe options
- PCIe Gen5, OCP 3.0 · iBMC
FusionServer 1288 V8 — 1U Dual Xeon 6
Current-generation high-density 1U on Intel Xeon 6 Granite Rapids: up to 288 cores, MRDIMM to 8000 MT/s and E3.S Gen5 NVMe for dense virtualization and all-flash HCI.
- 1U, 2 × Intel Xeon 6 (Granite Rapids, up to 144 cores each)
- 32 × DDR5/MRDIMM up to 8000 MT/s
- Up to 16 × E3.S Gen5 NVMe
- PCIe Gen5, OCP 3.0 · iBMC
FusionServer 2158H V8 — 2U Single EPYC
Single-socket 2U on AMD EPYC 9004/9005: up to 192 cores in one licensed CPU, 12 DDR5 DIMMs and up to four double-width GPUs for licensing-efficient, GPU-capable builds.
- 2U, 1 × AMD EPYC 9004/9005 (up to 192 cores)
- 12 × DDR5 up to 6400 MT/s
- Up to 24 × 2.5" (16 NVMe) · M.2 boot
- Up to 4 double-width GPUs · 10 PCIe Gen5
FusionServer 2258H V8 — 2U Dual EPYC
Dual-socket 2U on AMD EPYC 9004/9005: up to 192 cores per socket, 24 DDR5 DIMMs, up to four double-width GPUs and ten PCIe 5.0 slots for dense virtualization, databases and HPC.
- 2U, 2 × AMD EPYC 9004/9005 (up to 192 cores each)
- 24 × DDR5 up to 6400 MT/s
- Up to 24 × NVMe / 8 × 3.5" / 4 rear NVMe
- Up to 4 double-width GPUs · 10 PCIe Gen5 + 2 OCP
Previous generations — FusionServer V7 / V6 / V5
FusionServer 2288H V7 — 2U Dual Xeon
Versatile 2U dual-socket on 4th/5th Gen Intel Xeon Scalable with broad storage, GPU and PCIe Gen5 expansion.
- 2U, 2 × Xeon Scalable (Sapphire/Emerald Rapids)
- DDR5, PCIe Gen5 · front NVMe/SAS/SATA
- GPU-capable, hot-swap redundant PSU
FusionServer 1288H V7 — 1U Dual Xeon
Dense 1U dual-socket on 4th/5th Gen Xeon Scalable for rack-constrained virtualization and compute.
- 1U, 2 × Xeon Scalable (V7)
- DDR5 DIMMs · front NVMe/SAS
- Redundant PSU, counter-rotating fans
FusionServer 2258 V7 — High-Density Storage
Storage-rich FusionServer V7 chassis for software-defined storage, backup and bulk data nodes.
- High front-bay count chassis
- 2 × Xeon Scalable (V7), DDR5
- RAID, large-capacity SAS/SATA/NVMe
FusionServer 2288H V6 — 2U Dual Xeon
General-purpose 2U dual-socket on 3rd Gen Intel Xeon Scalable (Ice Lake) with PCIe Gen4.
- 2U, 2 × Xeon Scalable Gen3 (Ice Lake)
- DDR4, PCIe Gen4 · front NVMe/SAS
- Redundant PSU, GPU-capable
FusionServer 1288H V6 — 1U Dual Xeon
Compact 1U dual-socket on 3rd Gen Xeon Scalable for high-density mainstream fleets.
- 1U, 2 × Xeon Scalable Gen3
- DDR4 DIMMs · front hot-swap bays
- Counter-rotating fans, redundant PSU
FusionServer 2288H V5 — 2U Dual Xeon
Established 2U dual-socket on 1st/2nd Gen Intel Xeon Scalable; proven, cost-effective and fully supported.
- 2U, 2 × Xeon Scalable Gen1/Gen2
- DDR4, PCIe Gen3 · front NVMe/SAS/SATA
- Redundant PSU, GPU expansion
FusionServer 1288H V5 — 1U Dual Xeon
Dense 1U dual-socket on 1st/2nd Gen Xeon Scalable for value virtualization and compute.
- 1U, 2 × Xeon Scalable Gen1/Gen2
- DDR4 DIMMs · hot-swap front bays
- Redundant fans and PSU
FusionServer G5200 V7 — 4U 4 dual / 10 single GPUs
Flexible 4U accelerator server with dual 4th/5th-Gen Intel Xeon Scalable CPUs and a switchable topology for dense inference, training, VDI and HPC.
- 4U, 2 × Xeon Scalable (up to 350 W)
- Up to 32 DDR5 DIMMs
- 4 double- or 10 single-width GPUs
FusionServer G5500 V7 — 4U up to 10 GPUs
Flagship AI node with dual 5th-Gen Intel Xeon Scalable (Emerald Rapids) CPUs, DDR5 and PCIe 5.0 for large-model training and cloud inference.
- 4U, 2 × Emerald Rapids
- 32 × DDR5 · PCIe 5.0
- Up to 10 double-width GPUs
FusionServer G5500 V6 — 4U up to 8 GPUs
Proven value 4U platform with dual 3rd-Gen Intel Xeon Scalable (Ice Lake) CPUs, DDR4 and up to eight double-width accelerators.
- 4U, 2 × Ice Lake
- 32 × DDR4 · PCIe 4.0
- Up to 8 double-width GPUs
Choose by Generation and Workload
| Need | Model | Platform / generation |
|---|---|---|
| Newest high-density 1U on Xeon 6, MRDIMM and E3.S Gen5 | FusionServer 1288 V8 | V8 · 2 × Intel Xeon 6 (Granite Rapids) |
| Single-socket EPYC licensing efficiency with GPUs in 2U | FusionServer 2158H V8 | V8 · 1 × AMD EPYC 9004/9005 (up to 192 cores) |
| Dual-socket EPYC core density with 4 GPUs in 2U | FusionServer 2258H V8 | V8 · 2 × AMD EPYC 9004/9005 (up to 192 cores each) |
| Versatile 2U general-purpose on current Xeon Scalable | FusionServer 2288H V7 | V7 · 2 × Xeon Scalable Gen4/Gen5 |
| Dense 1U on current Xeon Scalable | FusionServer 1288H V7 | V7 · 2 × Xeon Scalable Gen4/Gen5 |
| High-capacity storage node | FusionServer 2258 V7 | V7 · storage-dense chassis |
| Proven DDR4 / PCIe Gen4 mainstream 2U | FusionServer 2288H V6 | V6 · 2 × Xeon Scalable Gen3 |
| Cost-effective DDR4 fleet value | 2288H V5 / 1288H V5 | V5 · 2 × Xeon Scalable Gen1/Gen2 |
Condition, Testing and Warranty
Every FusionServer we supply is new and factory-sealed. Current V8 units ship with a 3-year manufacturer
warranty, and sealed earlier-generation inventory carries a full 3-year warranty backed by Beijing Xinchuan Technology
Co., Ltd., so coverage does not depend on the original build date. Before shipment each configured build is assembled,
BIOS/firmware baselined and stress-tested (CPU, memory and drives), and we confirm chassis revision, controller and PSU
rating with the order. See the full warranty terms.
Batch Orders and Export
FusionServer is one of our most-requested brands for telecom and enterprise fleet projects. Multi-unit orders get
identical CPU steppings, matched DIMM layouts, same-batch drives and standardized iBMC firmware, palletized for export
with documentation support. Send destination, incoterm and target configuration — model, core count, RAM, storage,
networking, quantity — and we reply within one business day with a configured build, firm channel price and lead
time.
Frequently Asked Questions
Is xFusion the same company as Huawei servers?
xFusion was established from Huawei’s x86 server business and continues the FusionServer product line. It is an independent brand that carries forward the same engineering, tooling and quality system; FusionServer hardware and iBMC management remain familiar to teams that ran Huawei x86 servers.
Which xFusion models are current generation?
The current V8 line includes the 1U dual-socket 1288 V8 on Intel Xeon 6 and the 2U single-socket 2158H V8 and dual-socket 2258H V8 on AMD EPYC 9004/9005. Earlier V7, V6 and V5 FusionServers remain available as new sealed stock.
Do the servers come with a warranty?
Yes. Every unit we ship is new and factory-sealed with a 3-year warranty — manufacturer-backed on current V8, and backed by Beijing Xinchuan Technology Co., Ltd. on sealed earlier generations.
Can you supply complete racks or large batches?
Yes. We configure, match steppings and palletize multi-unit orders for export, with documentation and incoterm support. Send your BOM and destination and we quote a matched build.
What is the difference between the 1288 and 2288 chassis?
The 1288 is the 1U high-density form factor for rack-constrained compute; the 2288 is the 2U general-purpose platform with more storage, GPU and expansion room. The single-socket 2158H V8 adds a 2U one-CPU, licensing-efficient option.
Are FusionServers compatible with VMware, Linux and major cloud stacks?
Yes. FusionServer is certified and widely deployed with VMware vSphere, Microsoft, Nutanix, Proxmox and the major Linux distributions, with iBMC and FusionDirector for management.
Can you configure CPUs, memory, drives and GPUs to our specification?
Yes. Every build is configured to order, then stress-tested before shipment. Tell us the model and target specification and we confirm availability and price.
Do you ship internationally?
Yes, we export worldwide with standard incoterms and documentation. Multi-unit orders are palletized and we support destination-cleared or ex-works terms as requested.
